Module Overview
This PLC module handles basic digital control tasks for small machinery. You can install FUJI FDL120A-G02 directly into control panels or standalone enclosures. The unit processes digital inputs and drives transistor outputs locally. It operates without a separate CPU rack or backplane.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions (W x H x D) | 75 mm x 90 mm x 60 mm |
| Weight | 0.24 kg |
| Digital inputs | 8 points (24V DC, sink/source) |
| Input response time | 10 ms (fixed filter) |
| Digital outputs | 6 points (transistor, NPN sink type) |
| Output current rating | 0.3 A per point |
| Output response time | 2 ms typical |
| Program memory | 4 KB flash (approx. 2,000 steps) |
| Data memory | 1 KB RAM (battery-backed) |
| Scan time | 10 ms per 1,000 logic steps |
| Communication port | RS-485 (Modbus RTU slave) |
| Power supply | 24V DC (built-in) |
| Total onboard components | 118 discrete parts |
| Energy storage type | Super capacitor for program retention |
| Retention time | 48 hours without external power |
| Operating temperature | 0°C to +50°C |
Board Layout and Components
The PCB integrates CPU and I/O circuits on a single compact board. Eight optoisolators provide input filtering and electrical isolation. Additionally, 118 discrete components include transistor drivers and power regulation. A super capacitor retains program data for 48 hours after power loss. Consequently, you do not lose logic during short power interruptions.
Installation Process
You can mount FUJI FDL120A-G02 on a standard 35 mm DIN rail. The built-in screw terminals accept field wiring for all I/O points directly. Furthermore, a front panel RS-485 port connects to Modbus RTU networks. LED indicators show power, run, and I/O status clearly.
Performance Advantages
This module executes 1,000 ladder steps in approximately 10 milliseconds. The 2 ms output response handles basic machine sequencing adequately. Therefore, it suits conveyor controls, small packaging machines, and lighting systems. The Modbus slave port also allows connection to HMI panels easily.
Safety and Compliance
FUJI FDL120A-G02 meets CE and RoHS industrial standards. The unit stores negligible electrical energy after full power-down. Hence, technicians face no capacitor discharge hazards during maintenance.
