GE IS200STCIH6A IS200STCIH6ADD DIN Rail Contact Terminal Board

The GE IS200STCIH6A board terminates field wiring for Mark VI I/O signals. This DIN rail contact terminal board also carries the revision code IS200STCIH6ADD . It mounts directly on standard DIN rails for easy installation. The board connects sensors and actuators to the control system reliably.

Technical Specifications of GE IS200STCIH6A IS200STCIH6ADD

Component Count and Board Construction

The GE IS200STCIH6A board contains over 130 discrete components. You will find multiple suppression diodes for inductive loads. Furthermore, the board includes fuse holders for output channel protection. The assembly also features LED indicators for each signal path. The DIN rail clip mechanism ensures secure mounting without tools.

Interfaces, Energy Storage, and Signal Routing

The IS200STCIH6ADD revision provides screw terminal blocks for all field connections. Moreover, the board uses capacitors for minimal noise filtering. These capacitors store very little energy for transient suppression. Each terminal point includes a dedicated test point for troubleshooting. A ribbon cable connector interfaces with the main I/O module.

Functional Logic and Application Context

This Mark VI board routes discrete signals between field devices and I/O modules. It accepts inputs from limit switches, pushbuttons, and pressure switches. The GE IS200STCIH6A also delivers outputs to solenoids, valves, and indicator lights. Additionally, it provides common bus bars for shared power distribution. Consequently, the board simplifies field wiring and reduces installation errors.

Installation and Environmental Limits

You must isolate the 24 V DC supply before servicing this terminal board. The operating temperature range spans -30°C to +65°C . Furthermore, the board withstands 5 g vibration without connection loosening. Always verify the IS200STCIH6ADD labeling against your wiring diagram before connection. The DIN rail mounting allows quick replacement in crowded cabinets.
