GE IC695ALG608 Analog Input Module

Overview

The GE IC695ALG608 is an advanced analog input module designed for the PACSystem RX3i platform by GE Fanuc (now Emerson Automation). This module provides highly accurate data acquisition, offering up to eight (8) non-isolated, single-ended input channels or four (4) differential input channels. It supports a wide range of input signals, including +/-10 VDC, 0-10 VDC, +/-5 VDC, 0-5 VDC, 1-5 VDC, and 0-20 mA, among others. Equipped with a built-in 24-bit ADC, it converts analog signals to either floating point or integer data formats. This flexibility makes the IC695ALG608 ideal for high-precision industrial applications.

Key Features

Input Channel Options: Configures for either eight single-ended channels or four differential input channels.
Wide Input Signal Compatibility: Supports multiple signal types including 0-20 mA, 4-20 mA, +/-10 VDC, 0-10 VDC, and others.
High-Resolution ADC: Features a 24-bit ADC for accurate conversion of analog signals to floating-point or integer data.
Flexible Filtering: Configurable input filters including 8Hz, 12Hz, 16Hz, 40Hz, 200Hz, 500Hz to improve signal stability.
Power Supply: Operates with a backplane power supply, drawing a maximum of 330 mA at 5.0V and 600 mA at 3.3V.
Autocalibration: The module performs autocalibration during power-up for consistent performance.

Technical Specifications

Specification	Details
Part Number	IC695ALG608
Manufacturer	GE Fanuc (Emerson Automation)
Product Line	PACSystem RX3i
Module Type	Analog Input
Number of Channels	8 single-ended, 4 differential
Signal Types Supported	+/-10 VDC, 0-10 VDC, +/-5VDC, 0-5 VDC, 1-5 VDC, 0-20 mA, 4-20 mA, +/-20 mA
Resolution	24-bit ADC
Input Impedance (Voltage Inputs)	>100 kΩ
Current Input Resistance	249 Ω ±1%
Filter Options	8Hz, 12Hz, 16Hz, 40Hz, 200Hz, 500Hz
Voltage Range (for voltage signals)	+/-10V, 0-10V, +/-5V, 0-5V, 1-5V
Power Consumption	330 mA max @ 5V, 600 mA max @ 3.3V
Power Dissipation	4.83 watts maximum
Operating Temperature	0 to 60°C (32 to 140°F)
Storage Temperature	-40 to 85°C (-40 to 185°F)
Humidity	5% to 95%, non-condensing
Overvoltage Protection	±60 VDC continuous, max
Overcurrent Protection	±28 mA continuous, max
Backplane Power	330 mA max @ 5.0V, 600 mA max @ 3.3V
Module Dimensions	Standard RX3i module size (specific dimensions available upon request)

Installation Guidelines

Power Off the system before installing the IC695ALG608 module to avoid electrical hazards.
Mount the module on the RX3i universal backplane. It occupies one slot of the backplane.
Configure the input channels using the Machine Edition software (version 5.0 SP3 or later).
Select the appropriate terminal blocks: Compatible with Box-style, Extended Box-style, Spring-style, or Extended Spring-style terminal blocks.
Perform Autocalibration: The module automatically calibrates upon power-up, ensuring optimal performance.

Advanced Functionality

The GE IC695ALG608 provides essential features like open circuit detection, module fault reporting, and alarm settings to ensure seamless operation and quick identification of issues. It also supports interrupts for channel alarms and faults, enhancing system reliability. With its configurable input filters and 24-bit ADC, the IC695ALG608 delivers precise and stable data acquisition in dynamic industrial environments.

Conclusion

The GE IC695ALG608 analog input module is a versatile and reliable component in the PACSystem RX3i platform. It offers flexibility in input signal types, high-resolution data conversion, and customizable filters, making it ideal for a wide range of industrial applications. With advanced features like autocalibration and error checking, the IC695ALG608 ensures long-term reliability and precise data processing.
