GE IC660TBA106 Terminal Assembly Module

The IC660TBA106 provides field wiring termination for GE Genius I/O blocks. This terminal assembly module connects sensors and actuators to the Genius I/O system. You can rely on it for reliable signal distribution in distributed automation networks.

Key Technical Parameters

The table below lists all essential technical specifications for this terminal assembly module.

Specification	Details
Part Number	IC660TBA106
Product Type	Terminal Assembly Module
Compatibility	GE Genius I/O systems
Number of Terminals	20 screw terminal positions
Wire Gauge Range	0.2 mm² to 2.5 mm² (AWG 24-14)
Terminal Pitch	7.5 mm
Rated Voltage	250V AC / 30V DC
Rated Current	10 A per terminal
Dimensions (W x H x D)	180 mm x 100 mm x 35 mm
Weight	Approx. 0.35 kg
Connection Type	Removable screw connector
Housing Material	Polyamide (PA66)
Flammability Rating	UL94 V-0
Operating Temperature	-20°C to 70°C

Physical Characteristics and Installation

This terminal assembly module weighs approximately 0.35 kg for DIN rail mounting. Its dimensions measure 180 mm x 100 mm x 35 mm for Genius I/O blocks. First, clip the IC660TBA106 onto a 35 mm DIN rail. Then, connect your field wires to the 20 screw terminals. Finally, attach the module directly to your Genius I/O block. The removable connector allows easy wiring without detaching the base unit.

Terminal Specifications and Electrical Ratings

The IC660TBA106 provides 20 screw terminal positions for field signal wiring. Each terminal accepts wire gauges from 0.2 mm² to 2.5 mm². The terminal pitch measures 7.5 mm for comfortable access with standard tools. Each contact carries a rated current of 10 A. The rated voltage reaches 250V AC or 30V DC. Consequently, this unit suits both power and signal applications.

Material Properties and System Integration

The housing uses polyamide PA66 for excellent mechanical strength. A UL94 V-0 flammability rating ensures fire safety in control panels. The IC660TBA106 operates reliably between -20°C and 70°C. Therefore, it performs well in harsh industrial environments. The pluggable design speeds up module replacement and maintenance tasks. Use this terminal assembly with Genius I/O input and output blocks.
