GE IC610MDL153A Sink Output Module

The GE IC610MDL153A provides reliable sinking DC outputs for Series One PLC systems. This module manages up to 12 discrete output points. Each point delivers 24 VDC at 0.5 amps. You can use this unit for solenoids, indicators, or small relays. It operates within a 0 to 60 degrees Celsius range. Therefore, this module suits many factory automation tasks.

Physical Specifications and Energy Storage

This output module measures 120 mm in height and 85 mm in width. Its depth reaches 110 mm for standard rack mounting. The unit weighs approximately 0.32 kilograms. It contains three main internal subsections for signal isolation. The GE IC610MDL153A stores minimal energy in its filter capacitors. This storage does not exceed 50 microjoules under normal conditions. Consequently, the module discharges quickly after power loss.

Key Technical Specifications

Parameter	Value
Manufacturer	GE Fanuc Automation
Model	IC610MDL153A
Product Type	Sink Output Module
Number of Outputs	12 (sinking)
Output Voltage	24 VDC
Output Current per Point	0.5 A
Total Current per Module	6 A (maximum)
Height	120 mm
Width	85 mm
Depth	110 mm
Weight	0.32 kg
Energy Storage	≈ 50 µJ (capacitive)
Internal Components	3 main subsections
Operating Temperature	0°C to +60°C
Terminal Type	Removable screw block

Installation and Wiring Details

You mount the GE IC610MDL153A directly into a Series I/O rack. First, slide the module into the intended slot. Then, push the lever to lock it firmly. You need a common external power supply for all output channels. Connect the supply positive to each load. Finally, wire the load return to the module terminal. This configuration creates a proper sinking path. Always use fuse protection for each output point. The module provides optical isolation between the backplane and field side.

Performance and Usage Tips

This output module handles resistive loads without overheating. Inductive loads require a suppression diode across each coil. Otherwise, voltage spikes may damage the outputs. The GE IC610MDL153A shows a typical response time of 2 milliseconds. It can switch on and off at 1000 cycles per second. For longevity, do not exceed 80% of the maximum current. This practice keeps internal temperatures low. The removable terminal block simplifies field wiring changes.
