The GE IC600 BF900LCA1 transmits I/O data between Series Six PLCs and remote devices. You can install this module directly into any standard Series Six I/O rack slot. It converts parallel backplane signals into serial communication streams. This unit suits distributed I/O applications in large automation systems.
Technical Specifications and Hardware Layout
This I/O transmitter module measures 335 mm in height. Its width reaches 30 mm, and the depth equals 178 mm. The GE IC600 BF900LCA1 weighs approximately 0.52 kilograms. A single internal PCB holds all communication and isolation circuits. The module contains no energy storage capacitors or batteries. One 25-pin D-sub connector provides the serial communication interface. A 48-pin edge connector interfaces directly with the Series Six backplane. Two status LEDs indicate power and data activity.
| Parameter | Specification |
|---|---|
| Model | GE IC600 BF900LCA1 |
| Category | I/O Transmitter Module |
| Dimensions (H x W x D) | 335 mm x 30 mm x 178 mm |
| Weight | 0.52 kg |
| Internal PCBs | 1 |
| Energy Storage | None |
| Communication Interface | 25-pin D-sub |
| Backplane Interface | 48-pin edge connector |
| Status Indication | 2 LEDs |
| Isolation | 1500 V AC |
| Temperature Range | 0°C to 60°C |
Communication Performance and Specifications
The GE IC600 BF900LCA1 supports baud rates up to 153.6 kbit/s. It transmits up to 64 bytes of input and output data per scan. This module communicates with remote I/O racks using coaxial cable. Consequently, you can place I/O racks up to 500 meters from the main PLC. The module provides optical isolation between the field cable and backplane logic. A built-in watchdog timer resets communication after 100 ms of inactivity.
Installation and Diagnostic Features
You must snap this module firmly into a standard Series Six rack slot. Transitioning to wiring, use 75-ohm coaxial cable for maximum distance. Two front LEDs show power status and communication activity. The module includes a termination switch for end-of-line configuration. Always power off the PLC before removing or inserting the module. The operating temperature range spans from 0°C to 60°C reliably.
