GE DS200TCQEG2A DS200TCQEG2AED Processor Board

Key Technical Specifications

This GE DS200TCQEG2A DS200TCQEG2AED board operates from a 24V DC power supply. It runs a 32-bit processor at 200 MHz clock speed for control tasks. The unit measures 25 cm in length, 18 cm in width, and 5 cm in height. Its total weight reaches 0.9 kg without any packaging materials.

The GE DS200TCQEG2A DS200TCQEG2AED includes 64 MB of RAM and 32 MB of flash memory. Additionally, it features one VME backplane connector for system integration. A single 4-pin terminal block connects the DC power input. The board contains 1 CPU, 2 memory banks, 1 FPGA, 8 voltage regulators, 4 status LEDs, 1 battery, and 28 resistors.

Parameter	Value
Power Supply	24V DC ±10%, 500mA
Processor	32-bit RISC
Clock Frequency	200 MHz
RAM	64 MB SDRAM
Flash Memory	32 MB (non-volatile)
Dimensions (L x W x H)	25 cm x 18 cm x 5 cm
Weight	0.9 kg
Backplane Interface	VME64 P1/P2
Power Connector	4-pin terminal block
Status LEDs	4 units (Power, Run, Fault, Boot)
Real-Time Clock	1 unit (battery-backed)
CPU	1 unit
Memory Banks	2 units
FPGA	1 unit (I/O mapping)
Voltage Regulators	8 units
Battery	1 unit (lithium, 3V)
Resistors	28 units
Capacitors	24 units
Energy Storage	470 µF at 35V

GE DS200TCQEG2A DS200TCQEG2AED stores energy using two electrolytic capacitors. Together, they provide 470 µF at 35V rating for processor hold-up. This energy storage maintains operation during 30 millisecond power interruptions. Therefore, the board prevents data corruption during brief voltage sags.

Design and Integration

Both the GE DS200TCQEG2A and DS200TCQEG2AED versions share identical processor topology. These boards use eight-layer PCB construction with controlled impedance traces for high-speed signals. Consequently, the GE DS200TCQEG2A DS200TCQEG2AED operates reliably from 0°C to +55°C ambient temperature.

For installation, you need M3 screws for the four mounting holes. The board draws 400 mA typical current from the 24V DC supply. The backup battery retains CMOS settings for up to 5 years. We recommend using forced air cooling for high-temperature environments.

Practical Application

This processor board executes real-time control algorithms for turbine and generator systems. It runs application code for speed, load, and temperature regulation. The GE DS200TCQEG2A DS200TCQEG2AED communicates with I/O modules via the VME backplane. Therefore, it serves as the central computing unit for GE industrial control platforms.
