GE 44A713909-003 BUS Terminator Plug for Genius I/O Networks

The 44A713909-003 terminates the ends of Genius LAN bus segments. This terminator plug prevents signal reflections that disrupt network communication. You can rely on it for reliable data transfer in GE Genius I/O systems.

Key Technical Parameters

The table below lists all essential technical specifications for this bus terminator plug.

Physical Characteristics and Installation

This bus terminator plug weighs approximately 0.02 kg for very lightweight handling. Its dimensions measure 40 mm x 35 mm x 17 mm for compact installation. First, locate the first and last device on your Genius LAN segment. Then, plug the 44A713909-003 directly into the unused D-sub port. Finally, verify the terminator sits firmly in the connector. The device requires no tools or external power.

Termination Specifications and Network Requirements

The 44A713909-003 provides passive termination for Genius LAN bus segments. A built-in 150 Ω resistor network matches the characteristic impedance of the bus cable. Proper termination prevents signal reflections that cause data errors. You must install this terminator on both ends of every Genius LAN segment. Do not install terminators on intermediate network nodes.

Usage Guidelines and Compatibility

This bus terminator plug works with all GE Genius I/O network components. Use the 44A713909-003 on Genius blocks, master interfaces, and handheld monitors. The 15-pin D-sub male connector mates with standard Genius device ports. Always keep spare terminators for network maintenance. The black plastic housing resists typical industrial environment exposure.
