KJ3222X1-BA1 Analog Output Module 12P2532X122 CE4003S2B1

Origin: USA
Dimensions: 16.8 cm × 8.7 cm × 4.4 cm
Weight: 0.25 kg

The Emerson KJ3222X1-BA1 12P2532X122 CE4003S2B1 belongs to the DeltaV I/O family and delivers precise 4–20 mA HART analog output signals in fully redundant architectures. I use this module when I need uninterrupted analog output because each channel operates independently and continues to function even if the partner channel fails. This capability strengthens system reliability in demanding industrial processes.

Reliable Redundant Analog Output for DeltaV Systems

This module enhances signal integrity through channel-to-channel isolation, while HART support improves configuration flexibility and online diagnostics. Its compact DeltaV form factor fits tightly packed I/O enclosures, enabling efficient control system scaling.

Key Features

Provides two fully independent 4–20 mA HART analog output channels
Maintains uninterrupted control thanks to redundant architecture
Uses isolated channels to increase safety and protect field devices
Delivers fast and accurate output for tight industrial control loops
Offers LED indicators for real-time channel status feedback
Handles tough environments with rugged construction and wide temperature tolerance

Technical Specifications

Module Information

Parameter	Specification
Full Model Number	KJ3222X1-BA1 12P2532X122 CE4003S2B1
Type	4–20 mA HART Redundant Analog Output Module
Number of Channels	2
Output Signal	4–20 mA
HART Communication	Yes
Resolution	12 bits
Accuracy	1.0% of reading
Output Range	0–100% of reading
