EMERSON KJ3204X1-BK1 SE4002S1T2B6 Discrete Output Card

The EMERSON KJ3204X1-BK1 SE4002S1T2B6 is a high-performance 2-channel discrete output card designed for seamless integration with Emerson’s DeltaV automation systems. It provides precise control over industrial devices such as actuators, valves, and other automation equipment.

Key Features

High Current Capacity: Each channel delivers up to 3A, making it ideal for controlling high-power devices.
Short Circuit Protection: Integrated protection prevents damage to both the card and connected devices during short-circuit events.
Open-Load Detection: The card detects open loads, helping to identify and resolve issues with connected devices quickly.
Fault Isolation: Each channel operates independently, ensuring faults in one channel do not affect others.
LED Indicators: Each channel features an LED indicator for clear, real-time status feedback.

Technical Specifications

Specification	Details
Model Number	KJ3204X1-BK1 SE4002S1T2B6
Manufacturer	Emerson
Type	2-Channel Discrete Output Card
Input Voltage	24 VDC
Output Capacity per Channel	3A
Protection	Short Circuit, Open-Load Detection
Fault Isolation	Yes (Channel Isolation)
Environmental Temperature	-40°C to +70°C
Shock Rating	10g ½ Sinewave for 11msec
Vibration Resistance	1mm Peak-to-Peak from 2 to 13.2Hz, 0.7g from 13.2 to 150Hz
Airborne Contaminants	ISA-S71.04 – 1985 Class G3
Relative Humidity	5 to 95% Non-Condensing
IP Rating	IP20
Terminal Block Key Position	B4

Design and Performance

The KJ3204X1-BK1 SE4002S1T2B6 excels in controlling devices that demand high current, delivering up to 3A per channel. Integrated short circuit protection ensures the safety of both the card and the connected devices. Additionally, its open-load detection feature allows quick troubleshooting and efficient fault management. The fault isolation design prevents issues in one channel from spreading to others, contributing to overall system reliability.

With LED indicators for each channel, operators can quickly check the status of the card. This provides real-time visual feedback, which enhances operational monitoring and maintenance.

Environmental and Operating Conditions

The KJ3204X1-BK1 SE4002S1T2B6 operates within a broad temperature range of -40°C to +70°C, making it suitable for use in extreme environments. It can withstand shocks of up to 10g and vibrations ranging from 2 to 150Hz, making it highly reliable in industrial settings.

The card supports a relative humidity range of 5-95% (non-condensing) and is rated IP20, offering protection against dust and airborne contaminants. This combination of features ensures the card’s durability and reliability in harsh industrial conditions.

Applications

The EMERSON KJ3204X1-BK1 SE4002S1T2B6 is ideal for a wide range of industrial automation applications, including:

Process Control: Manages actuators and other devices in automated process control systems.
Manufacturing Automation: Integrates with automated production lines for reliable device control.
Robotics: Provides precise control for robotic systems, improving accuracy and efficiency.
Material Handling: Controls devices in conveyors, lifts, and other material handling equipment.
HVAC Systems: Used for HVAC control in building automation, optimizing energy management.

Why Choose the EMERSON KJ3204X1-BK1 SE4002S1T2B6?

The KJ3204X1-BK1 SE4002S1T2B6 offers robust performance, advanced features, and high reliability. It is the ideal choice for controlling high-power devices in demanding automation applications. Its combination of short circuit protection, open-load detection, and fault isolation ensures reliable operation. Whether in process control, manufacturing, robotics, or HVAC systems, this card provides precise control and improves system uptime.
