Bently Nevada 3500/40 149716-01 Transient Measurement Module

High-Speed Data Capture for Precise Transient Event Monitoring

The Bently Nevada 3500/40 149716-01 is a highly efficient Transient Measurement Recording (TMR) Proximitor I/O Module designed specifically for the 3500/40M ENCORE Monitoring System. It offers a comprehensive solution for detecting and analyzing transient events such as shock, vibration, and impact that can damage sensitive machinery. With this module, operators can accurately capture and assess even the most rapid transient occurrences.

This 149716-01 module is engineered to sample data at high speeds and store extensive transient waveform data. It seamlessly integrates with the 3500/40M ENCORE monitoring system to provide detailed insights into machine health. By enabling advanced signal processing and real-time fault detection, this module plays a critical role in minimizing downtime and extending the lifespan of industrial equipment.

Key Features

Rapid Data Capture: The 149716-01 module captures transient events at up to 250 kHz, ensuring accurate measurements of high-speed vibrations and impacts.
Ample Storage Capacity: It provides large data storage for continuous monitoring of transient events, supporting extensive waveform data.
Advanced Signal Processing: Equipped with advanced algorithms, the module offers high-pass and low-pass filtering, peak detection, and RMS calculation for in-depth fault analysis.
Effortless System Integration: The 149716-01 integrates seamlessly with the 3500/40M ENCORE monitoring system, offering a unified platform for data collection, analysis, and visualization.

Technical Specifications

Feature	Specification
Data Sampling Rate	Up to 250 kHz
Data Storage Capacity	GB
Signal Processing	High-pass and low-pass filtering, peak detection, RMS calculation
Communication Protocol	Ethernet
Operating Temperature Range	-40°C to +70°C (-40°F to +158°F)
Environmental Protection	NEMA 4, IP65

Physical Dimensions and Weight

Dimension	Specification
Size	Compatible with 3500/40M ENCORE system
Weight	Approx. 0.7 kg (1.54 lbs)

Applications

The Bently Nevada 3500/40 149716-01 module is ideal for industries where transient events can cause significant harm to machinery. It is commonly used in power generation, petrochemical, and manufacturing plants where the protection of critical machinery is essential. With its ability to capture rapid vibrations, impacts, and shocks, the 149716-01 ensures that operators can detect and address potential faults before they lead to equipment failure.
