Bently Nevada 3300/05-22-00-00 6-Slot Monitoring Rack

Chassis Enclosure for 3300 Series Transducer Monitors

The Bently Nevada 3300/05-22-00-00 six-slot rack provides a rugged chassis for housing 3300 series monitor modules. This enclosure accepts up to six individual monitors for continuous machinery protection applications. The rack forms the physical backbone of your vibration monitoring system infrastructure.

Mechanical Specifications at a Glance

Structural and Connectivity Features

The chassis incorporates a precision-engineered backplane for simplified module installation. Each of the six card slots provides a consistent mechanical and electrical interface. This rack includes a 22-conductor termination option for straightforward field wiring connections. The internal bus architecture distributes power and signal buses efficiently to every occupied slot.

Design for Industrial Reliability

This rack operates effectively across a wide industrial temperature range from -30°C to +65°C. A corrosion-resistant finish protects the steel housing in harsh plant environments. The convection cooling design eliminates the need for fans. Consequently, this approach reduces maintenance requirements over the system lifetime.

Installation Considerations

Mounting provisions accommodate both standard 19-inch racks and custom panel installations. The 3300/05-22-00-00 also provides clear labeling for each slot position. Physical keying prevents incorrect module insertion. Moreover, the robust construction ensures reliable performance even under significant mechanical vibration.

System Integration Options

This rack integrates seamlessly with 3300/12 power supplies and 3300/14 dual supplies. The backplane supports both DC and AC power distribution. Operators can populate any combination of 3300 monitor cards. This flexibility allows customized system configurations for specific applications.
