Reliable Safety Control for Industrial Systems
The Allen-Bradley 700S-DCP710DZ24 is a high-performance safety relay designed for demanding automation environments. It operates with a 24V DC coil and supports up to 600V contact rating, making it ideal for controlling safety circuits and machine interlocks in industrial facilities. Its durable open-type DIN rail mount design ensures easy installation and long-term stability in panel applications.
Technical Specifications
| Specification | Description |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model | 700S-DCP710DZ24 |
| Category | NEMA Safety Relay |
| Rated Control Supply Voltage (DC) | 24 V |
| Contact Rating (Continuous) | 5 A @ 600 V DC |
| Mounting Method | DIN-rail or screw mounting |
| Connection Type | Screw terminals |
| Wire Size | #18 AWG to (2) #12 AWG (per UL/CSA) |
| Mechanical Life | 10,000,000 operations |
| LED Indication | No |
| Manual Operation | Not supported |
| Operating Temperature | -20 °C |
| Storage Temperature | -40 °C |
| Interface | No interface included |
Key Features and Benefits
- The 700S-DCP710DZ24 ensures stable operation in both low- and high-voltage environments.
- Its rugged NEMA 600V rating provides reliable electrical isolation and system protection.
- DIN-rail installation allows quick setup and replacement in automation cabinets.
- The compact structure and high contact life minimize downtime and maintenance.
- Designed for precision safety applications where consistent control is critical.
Dimensions and Weight
- Mounting Type: Open-style DIN rail
- Approximate Weight: 0.35 kg (0.77 lbs)
- Overall Dimensions (W × H × D): 45 mm × 90 mm × 100 mm
Origin
- Country of Manufacture: United States
