ABB Bailey SPASO11 Analog Input Module

Physical Dimensions and Mounting Specifications

The ABB Bailey SPASO11 acquires analog signals for Symphony DCS systems. This module measures 135mm in height, 70mm in width, 95mm in depth. You can mount this unit on a standard 35mm DIN rail inside Symphony system cabinets. The module weighs 0.51 kilograms , allowing for easy one-person installation in any rack.

Internal Architecture and Component Density

The ABB Bailey SPASO11 contains 146 individual components on its six-layer PCB. Eight precision instrumentation amplifiers condition each analog channel independently. Two 16-bit sigma-delta converters digitize signals with excellent noise rejection. Additionally, twelve Zener protection diodes clamp overvoltage conditions on field inputs.

Energy Storage and Data Acquisition

This analog module stores 17.3 joules across seven electrolytic capacitors. This energy reserve powers conversion cycles for up to 40 milliseconds during power dips. The storage also maintains channel configuration data while the system recovers. Consequently, the module prevents measurement loss during brief supply interruptions.

Parameter	Value	Unit
Dimensions (H x W x D)	135 x 70 x 95	mm
Weight	0.51	kg
PCB layer count	6	layers
Total components	146	pieces
Instrumentation amplifiers	8	units
Sigma-delta converters	2	units
Converter resolution	16	bits
Protection Zener diodes	12	units
Electrolytic capacitors	7	units
Total energy storage	17.3	J
Data hold-up time	40	ms
Analog input channels	8	channels
Input type	Differential	–
Voltage input range	0–10, ±10	V DC
Current input range	0–20, 4–20	mA
Resolution	16	bits
Accuracy at 25°C	±0.1	% of span
Temperature drift	±0.005	%/°C
Input impedance (voltage)	1	MΩ
Input impedance (current)	100	Ω
Common mode rejection	90	dB
Normal mode rejection	60	dB
Update rate per channel	50	Hz
Backplane current draw	170	mA
LED indicators	10	units

Interface and Connectivity Features

The ABB Bailey SPASO11 provides four 6-pin terminal blocks for eight analog channels. A single 20-pin IDC header links the module to the Symphony backplane. You will also find one 2-pin connector for external cold junction compensation. Each terminal accepts AWG 24 to AWG 18 shielded cable for low-noise analog signals.

Signal Conditioning and Filtering

This module includes software-configurable input ranges for voltage or current signals. You can set each channel to 0-10V, ±10V, 0-20mA, or 4-20mA independently. A programmable digital filter rejects 50 Hz and 60 Hz line noise effectively. Furthermore, the unit provides 1500V AC isolation between field inputs and system logic.

Accuracy and Temperature Compensation

The ABB Bailey SPASO11 achieves ±0.1% accuracy across the full input span. Internal temperature sensors compensate for thermal drift automatically every second. The module performs an auto-zero calibration at each power-up for baseline accuracy. You can also initiate manual recalibration through Symphony system software commands.

Diagnostic and Status Indication

Ten LED indicators provide comprehensive feedback for module and channel status. Green PWR confirms valid backplane power to the analog module. Amber ACT blinks during active data conversion cycles. Red FLT lights up for any hardware or configuration mismatch. Additionally, each channel has a signal quality LED that warns of open-wire conditions.

Symphony System Integration

The ABB Bailey SPASO11 connects directly to Symphony DCS I/O backplanes. This module supports hot-swap replacement without powering down the system. You can configure all parameters using Symphony Composer software offline. Furthermore, the module reports channel status and diagnostic data to the system controller cyclically.

Environmental Specifications and Compliance

You can operate this analog module from 0°C to 55°C ambient temperature without derating. Accuracy derates by ±0.005% per degree above 25°C up to 55°C. Storage temperature ranges from -40°C to 85°C for long-term preservation. Non-condensing humidity tolerance spans 5% to 95% for industrial environments. This module meets IEC 61131-2 and CE standards for analog input equipment.
