ABB 200-IP2 Pulse Counter Module

The 200-IP2 captures high-speed pulse signals for ABB control systems. This module counts pulses from encoders, flow meters, or frequency generators. You can use it for position feedback or totalizing applications.

Key Technical Parameters

The table below lists all essential technical specifications for this pulse counter input module.

Specification	Details
Part Number	200-IP2
Product Type	Pulse Counter Input Module
Compatibility	ABB distributed I/O systems
Number of Channels	2 independent counter channels
Maximum Input Frequency	50 kHz per channel
Input Voltage Range	5V to 24V DC
Input Types	RS-422 differential, single-ended
Counter Resolution	32 bits
Counter Modes	Up, down, up/down, quadrature
Input Impedance	10 kΩ
Isolation	1500V AC (channel to bus)
Dimensions (W x H x D)	160 mm x 120 mm x 45 mm
Weight	Approx. 0.38 kg
Terminal Type	Screw terminal block
Power Supply	5V DC from backplane + 24V DC external
Current Consumption	200 mA (logic) + 50 mA (field)
Operating Temperature	0°C to 55°C

Physical Characteristics and Installation

This pulse counter module weighs approximately 0.38 kg for standard rack mounting. Its dimensions measure 160 mm x 120 mm x 45 mm for distributed I/O chassis. First, slide the 200-IP2 into a free slot in your I/O rack. Then, connect your pulse sources to the screw terminals. Finally, configure the counter modes through your control software. LED indicators show power status and pulse activity per channel.

Input Specifications and Counting Modes

The 200-IP2 provides 2 independent counter channels for flexible measurement. Each channel accepts input frequencies up to 50 kHz for high-speed applications. You can connect either RS-422 differential or single-ended signals. The module offers four counting modes for various needs. Up mode counts positive pulses only. Down mode decrements from a preset value. Up/down mode uses two signals for direction. Quadrature mode decodes encoder A/B signals for position tracking.

Resolution and Isolation

A 32-bit counter resolution stores up to 4.2 billion counts per channel. This large range suits long-term totalizing without overflow. 1500V AC isolation separates each counter channel from the backplane bus. Consequently, this design protects the controller from electrical noise. The 200-IP2 requires both 5V DC logic power and 24V DC field power for operation.
