ABB 1SAP245200R0001 Switch Input/Output Module for AC500

The 1SAP245200R0001 combines digital inputs and outputs in a single compact unit. This mixed module saves cabinet space for ABB AC500 systems. You can use it for small machine control or simple sequencing tasks.

Key Technical Parameters

The table below lists all essential technical specifications for this switch I/O module.

Physical Characteristics and Installation

This I/O module weighs approximately 0.24 kg for straightforward DIN rail mounting. Its dimensions measure 105 mm x 95 mm x 65 mm for standard AC500 footprint. First, clip the 1SAP245200R0001 onto a 35 mm DIN rail. Then, connect your sensors and actuators to the spring-clamp terminals. Finally, attach the module to the left-side bus connector. LED indicators show the real-time status for every channel.

Input Specifications and Signal Detection

The 1SAP245200R0001 provides 16 digital input channels for field devices. Each channel accepts 24V DC nominal signals from switches and sensors. The input current measures only 6 mA per active channel. A fast 1.5 ms response time captures short machine events reliably. Optocouplers isolate every input from the internal logic circuits for safety.

Output Specifications and Protection Features

This module delivers 8 transistor outputs for driving small actuators. Each output supplies up to 0.5 A at 24V DC. Built-in short-circuit protection prevents damage from wiring mistakes. Overload protection shuts down the affected output automatically. The 1SAP245200R0001 responds to output commands in just 1 ms. Spring-clamp terminals provide fast, vibration-proof wiring without special tools.
