ABB 1SAP250100R0001 Analog Input/Output Module

This analog I/O module handles both sensor reading and actuator control tasks. It combines four input channels and two output channels in one unit. Therefore, this component saves rack space while providing mixed signal capabilities.

Physical Dimensions and Weight Specifications

The ABB 1SAP250100R0001 features a slim housing for DIN rail mounting. Its width measures 56 mm for standard industrial enclosures. The total depth reaches 73 mm including the connector terminals. Consequently, technicians can install this module in tight cabinet spaces.

Interface Types and Connection Layout

The ABB 1SAP250100R0001 provides spring-clamp terminals for field wiring. A 10-pin backplane connector supplies power and data from the CPU. The front panel carries six LED indicators for channel status. Hence, operators can monitor both inputs and outputs at a glance.

Component Count and Channel Configuration

This analog I/O module contains one main board with six analog circuits. The board holds 4 analog input channels for 0-10V or 4-20mA signals. You will also find 2 analog output channels for actuator control. An onboard 12-bit ADC handles input conversion while a DAC manages outputs.

Energy Storage and Power Consumption

The ABB 1SAP250100R0001 draws 70 mA from the 5V backplane supply. It also requires 50 mA from an external 24V supply for field circuits. A small capacitor bank filters noise on the analog power rails. This storage reduces measurement errors from power supply fluctuations.

Accuracy and Conversion Performance

The module achieves ±0.2% accuracy for inputs and ±0.3% for outputs. It scans all four inputs within a 4 ms cycle time. Users can configure each channel independently via software. This flexibility supports mixed signal types within a single module.
