Technical Overview
The Honeywell CC-GAOX11 is a redundant analog output module engineered for the Experion PKS Series C distributed control system. This unit converts digital control signals from the C300 controller into precise analog outputs for driving field actuators, valves, and other process instruments . It provides a dedicated 1:1 redundancy configuration across all channels, enabling seamless failover and ensuring uninterrupted process control in critical applications .
The module supports both voltage and current output modes, giving users flexibility for various industrial control tasks . Its robust industrial-grade construction ensures stable performance in demanding environments . This unit integrates seamlessly with Series C I/O Termination Assemblies (IOTA) via standard DIN rail mounting . It includes comprehensive diagnostic capabilities for proactive fault detection.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | CC-GAOX11 |
| Product Type | Redundant Analog Output Module |
| System Compatibility | Experion PKS Series C, C300 Controller |
| Number of Channels | 8 (redundant 1:1 configuration) |
| Output Signal Type | 4-20 mA current (configurable) |
| Accuracy | ±0.1% of full scale |
| Resolution | 14-bit or 16-bit |
| Response Time | ≤10 ms typical, ≤1 ms available |
| Isolation | High-voltage isolation between channels and power supply |
| Power Supply | 24 VDC nominal |
| Power Consumption | ≤6 W typical |
| Operating Temperature | 0°C to +60°C (standard), -40°C to +85°C for extended variants |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Mounting | DIN rail compatible, Series C IOTA baseplate |
| Dimensions | 220 x 130 x 40 mm (approx.) |
| Weight | 0.8 kg |
| Certifications | CE, UL, CSA, RoHS |
| Country of Origin | USA |
Key Features
Redundant Architecture – The module implements a fully redundant 1:1 backup for all eight channels, automatically switching to the backup path upon fault detection and ensuring continuous operation for critical loops .
High Accuracy and Resolution – With ±0.1% full-scale accuracy and up to 16-bit resolution, this module delivers precise signal control for demanding process applications .
Configurable Output Range – Each channel supports 4-20 mA current output, accommodating various industrial actuators and instruments .
Compact and Robust Design – The module’s space-efficient form factor and rugged metal housing withstand harsh industrial environments while saving cabinet space .
Hot-Swap Capability – Users can replace the module without powering down the system, minimizing downtime during maintenance .
Built-in Diagnostics – The module provides continuous self-monitoring with LED status indicators for power, communication, and channel health .
Applications
The Honeywell CC-GAOX11 excels in oil and gas, chemical processing, power generation, pharmaceutical manufacturing, and water treatment industries. It is ideal for critical process control loops, valve positioning, and actuator control in Experion PKS-based distributed control systems
