ABB 07 ZW 80 Procontic B Module | 8 Inputs / 8 Outputs

This module provides discrete I/O processing for ABB Procontic controllers. The ABB 07 ZW 80 handles digital signals between field devices and the CPU. It measures 180 mm in width and 120 mm in height. This unit weighs approximately 0.45 kg for rack mounting.

Technical Specifications Table

Parameter	Value
Product Model	ABB 07 ZW 80
Brand	ABB
Category	Procontic B Module / I/O Module
Compatible Series	ABB Procontic PLC
Digital Inputs	8 channels (24 V DC, sink/source)
Digital Outputs	8 channels (24 V DC, 0.5 A)
Total I/O Points	16 points
Input Delay	5 ms typical
Output Delay	1 ms typical
Dimensions (W x H x D)	180 mm x 120 mm x 50 mm
Weight	0.45 kg
Connector Type	1 x 20-pin screw terminal block
Internal Components	8 x optocouplers (inputs), 8 x power transistors (outputs)
Electrical Isolation	1500 V RMS between I/O and backplane
Energy Storage	None (I/O updates in real time)
Operating Voltage	5 V DC (from backplane), 24 V DC (field supply)
Power Consumption	100 mA at 5 V, 80 mA at 24 V
LED Indicators	16 x green (input/output status), 1 x green (power)
Operating Temperature	0°C to 55°C

Internal Design and I/O Processing

This B module uses eight optocouplers for input signal isolation. Eight power transistors drive output loads for field devices. The ABB 07 ZW 80 scans inputs and updates outputs every 10 milliseconds. The module stores no I/O states after power loss. Consequently, the CPU reads fresh input values during each scan cycle. Green LEDs on the front panel show the real-time status of all 16 channels.

Installation and Wiring Guide

First, mount this module into any Procontic rack slot securely. Next, connect your 24 V DC field supply to the designated power terminals. Then, wire your sensor outputs to the 8 input channels (I1-I8). Wire your load devices to the 8 output channels (O1-O8). Each output handles up to 0.5 A of continuous current. Use a 0.5 A fast-blow fuse for each output channel externally. The module provides LED indicators for power and I/O status. This B module works with ABB Procontic CPU modules and expansion racks. Always verify the output wiring polarity before applying power to the module.
