ABB 07 ES 80 Analog Input Module

Technical Specifications and Input Features

The ABB 07 ES 80 analog input module belongs to the ABB Advant OCS product family as part of the S100 I/O series . This module provides 8 differential analog input channels for high-precision signal acquisition . It accepts standard industrial signals including 4-20mA current and 0-10V voltage inputs . The module features 12-bit resolution for accurate measurement of process variables . It connects to field devices via a 20-pin terminal block interface . The unit’s compact design ensures straightforward installation in control cabinets .

Functional Capabilities

The 07 ES 80 module actively converts analog field signals into digital values for the PLC processor. It handles both current and voltage inputs, providing flexibility for various sensor types . The module’s 12-bit resolution delivers accurate representation of process variables like temperature, pressure, and flow . Its high input impedance minimizes signal loading on field devices . The module performs self-diagnostics to ensure reliable data acquisition and fault detection .

Application Scenarios

This analog input module suits process monitoring applications requiring multiple analog signal acquisitions . It integrates with ABB Advant controllers and S100 I/O system components. The ABB 07 ES 80 serves in applications such as HVAC control and industrial machine monitoring . Many legacy ABB systems continue to rely on this module for analog signal processing.
