The ABB 1SAP260100R3001 positioning module, also known as PD501-4CH, belongs to the AC500 PLC platform and the S500 I/O family . This module provides precise motion control for demanding positioning applications. It operates on a supply voltage of 24V DC and features four independent channels (4CH) for multi-axis control. The module’s compact dimensions measure 6.00 cm x 7.00 cm x 8.00 cm and it weighs only 0.11 kg . It mounts onto a standard S500 terminal base for seamless system integration . The module originates from Germany and has a shipping weight of 1.00 kg .
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | 1SAP260100R3001 |
| Product Name | PD501-4CH |
| Product Family | AC500 / S500 I/O |
| Module Type | Positioning Module |
| Channels | 4 (independent) |
| Supply Voltage | 24V DC |
| Country of Origin | Germany |
| Item Weight | 0.11 kg |
| Shipping Weight | 1.00 kg |
| Dimensions (L x W x H) | 6.00 x 7.00 x 8.00 cm |
| Mounting | Terminal base |
| Customs Tariff Number | 85389091 |
Functional Capabilities
The 1SAP260100R3001 module actively executes positioning tasks for industrial automation applications. It operates as a function module, providing independent components such as a CPU and memory for dedicated motion control tasks . The module communicates with the PLC through the I/O bus, exchanging data and working independently under the PLC’s coordinated management . Consequently, this positioning module enables precise control of servo drives and stepper motors. It offers reliable performance for demanding positioning applications, contributing to efficient and accurate machine operations.
Application Scenarios
This positioning module suits a wide range of industrial automation applications requiring precise motion control. It integrates seamlessly into AC500 PLC systems for packaging, material handling, and assembly tasks. The ABB 1SAP260100R3001 also proves valuable in machine tool and robotics applications. Its compact footprint makes it ideal for space-constrained control cabinets. This module serves as a practical solution for both new installations and system expansions.
