2VAA008574R1 | ABB cHBX01L Compact Bus Extender Horizontal Left

Overview

The cHBX01L Compact Bus Extender is designed for connecting to the left side of the HN800 device row. This extender enables seamless communication between devices while also providing a 24 VDC module power connection for enhanced functionality. It is part of ABB’s **Symphony Plus** and **S+ SD I/O** systems.

Product Identification

• Product ID: 2VAA008574R1
• ABB Type Designation: cHBX01L
• Catalog Description: Compact Bus Extender, Horizontal row, connects to LEFT side of HN800 devices row
• Product Type: Control System Accessory

Technical Specifications

• Dimensions: 48 mm (Depth) × 127 mm (Height) × 30 mm (Width)
• Product Net Weight: 0.094 kg
• Voltage Connection: Provides connection for 24 VDC Module Power
• WEEE Category: 5 – Small Equipment (No external dimension more than 50 cm)
• Number of Batteries: 0

Ordering Information

• HS Code: 85371091 – Electric control or distribution equipment, not exceeding 1,000 V
• Customs Tariff Number: 85371091
• Minimum Order Quantity: 1 piece
• Selling Unit: Piece

Environmental Compliance

This product is **not subject** to WEEE regulations and contains **no SVHCs** (Substances of Very High Concern). Handle and dispose of in accordance with local environmental regulations.

Applications

The  cHBX01L  bus extender is ideal for use in **Symphony Plus** and **S+ SD I/O** systems, providing critical connections for power and data flow between modules. It is used in industrial environments requiring compact and reliable connectivity for control systems.
