Yokogawa CP345 cPCI Graphics Board

Meet the Yokogawa CP345, a powerful 3U CompactPCI graphics board designed for intensive visualization tasks. This advanced module delivers exceptional multi-display performance in rugged industrial and embedded computing environments. Consequently, it is ideal for control room dashboards, simulation systems, and medical imaging applications. Moreover, its robust design ensures reliable operation under challenging physical conditions.

Detailed Technical Specifications

Engineered for high-resolution output, the CP345 integrates leading-edge graphics technology. Here are the precise technical parameters for system integration and compatibility assessment.

Parameter	Specification
Form Factor & Type	3U CompactPCI (cPCI) Graphics Board
Board Dimensions (W x D)	100.07 mm x 161.79 mm (3.94″ x 6.37″)
Board Width	4HP (0.8 inches)
Video Memory	4 GB GDDR5
Video Output Ports	5 x Independent Mini DisplayPort 1.4
Max. Resolution per Port	4096×2160 @ 60 Hz (4K Display)
Dual-Cable Resolution	Up to 5120×2880 @ 60 Hz
Host Bus Interface	PCI-X 64-bit/32-bit @ 133 MHz
Compliance Standards	PICMG 2.0 R3.0, CompactPCI Type cPCI
Typical Power Consumption	40 W
Operating Temperature	0 to 55°C (Commercial)
Storage Temperature	-40° to +90°C
Vibration Resistance	9.8 m/s² (1G), 5 to 500 Hz (all axes)
Shock Resistance	30G (all axes)
Relative Humidity	5 to 95% (non-condensing)

Core Features & System Integration

This graphics board supports up to five independent high-resolution displays simultaneously. Therefore, it provides exceptional flexibility for complex multi-monitor setups in compact systems. Additionally, the 4GB GDDR5 memory and DirectX 12 support enable smooth rendering of complex graphical interfaces.

The front panel features five Mini DisplayPort connectors alongside status LEDs. Furthermore, its hot-swap ejector handle facilitates easy maintenance without powering down the entire system. For system builders, combining the CP345 with a robust RMS-TSG-TZ-C Static Trip protection device ensures comprehensive system reliability.

Its compliance with PICMG 2.0 R3.0 standards guarantees seamless integration into standard cPCI backplanes. Similarly, the board supports major operating systems including Linux and Windows. This versatility makes it a future-proof choice for diverse software environments.

Engineered for Reliability in Harsh Conditions

Choosing the Yokogawa CP345 means selecting a graphics solution built for mission-critical durability. Its specifications for shock, vibration, and wide temperature ranges exceed typical commercial requirements. Ultimately, this module delivers unwavering visual performance where stability is non-negotiable.
