Yokogawa AVR10D Dual-Redundant V-Net Router

The Yokogawa AVR10D is a high-performance router designed for dual-redundant network configurations. It is specifically developed to integrate seamlessly with CENTUM systems, facilitating smooth communication and data exchange across industrial networks. This router ensures continuous network operation, even when one path fails, making it essential for reliable industrial communication.

Key Features of the Yokogawa AVR10D

Dual-Redundant Network Configuration: With its dual-redundant setup, the AVR10D ensures uninterrupted communication, even if one network path experiences failure. This feature is crucial for industrial control systems where downtime is unacceptable.
High-Speed Communication: The router supports high-speed communication at 100 Mbps Vnet/IP and 10 Mbps Vnet. This high-performance feature ensures real-time data transfer across networks, which is vital for time-sensitive applications.
Versatile Connectivity: The AVR10D is compatible with both Vnet and Vnet/IP protocols, offering flexibility for various industrial network configurations. This versatility ensures that it meets diverse operational needs.
Modular Design: Its modular design simplifies installation, maintenance, and future upgrades. Additionally, this design approach minimizes downtime and maximizes operational efficiency.
Robust and Durable: Built to withstand tough industrial environments, the AVR10D ensures long-term reliability and performance, even under extreme conditions.

Technical Specifications

The AVR10D router delivers outstanding performance and versatility, with the following key specifications:

Feature	Specification
Model	AVR10D
Type	Dual-redundant V-net Router
Suffix Codes	Q2 = Dual-Redundant V-net (10BASE-2)
	2 = Dual Power Supply
	0 = Always 0
	2 = 220-240 V AC Power Supply
	0 = Basic type
Power Supply	100-120 V AC or 220-240 V AC, 50/60 Hz
Power Consumption	Approximately 20 W
Communication Interfaces	Vnet/IP: 100 Mbps, full-duplex, RJ45 connector
	Vnet: 10 Mbps, dual-redundant or single, BNC connector
Dimensions	210 mm (W) x 230 mm (H) x 80 mm (D)
Weight	Approximately 2.5 kg
Operating Temperature	-10°C to +55°C
Operating Humidity	5% to 95% RH

Additional Features

Dual-Redundancy: The AVR10D guarantees constant network operation, even if one path fails. Thus, it offers crucial reliability for industrial processes.
High-Speed Performance: The router ensures fast and efficient data transfer at 100 Mbps for Vnet/IP and 10 Mbps for Vnet, ensuring timely data availability in real-time operations.
Modular Design: The modular architecture makes installation, maintenance, and upgrades easy. This ensures minimal downtime and keeps your network systems running efficiently.
Versatile Connectivity: The AVR10D is compatible with both Vnet and Vnet/IP protocols, making it adaptable to diverse industrial network needs.
Rugged Construction: The AVR10D is engineered to endure tough industrial environments, providing long-term reliability and performance.

Manufacturer Information

The Yokogawa AVR10D is manufactured by Yokogawa, a trusted name in industrial automation. Yokogawa’s commitment to high-performance products makes the AVR10D an excellent choice for ensuring reliable and uninterrupted network communications in industrial systems.
