Woodward 5417-027 NetCon LoDen Analog Cable

Overview

The Woodward 5417-027 NetCon LoDen Analog Cable is an essential component for signal integrity in industrial systems. It protects against electromagnetic interference (EMI) by using the enclosure as a shield termination point. This ensures that the cable’s performance remains reliable, even in environments with high levels of external electrical noise.

Key Features

• Enhanced Signal Protection: The Woodward 5417-027 cable offers high-quality shielding, preventing signal degradation caused by EMI.
• Flexible Grounding Options: With AC (capacitive) or DC termination methods, you can ensure secure grounding tailored to your system’s needs.
• Reliable Installation: The cable’s termination hardware makes installation straightforward and ensures solid electrical connections.
• Improved Signal Integrity: Proper shield connections maintain the integrity of analog signals, ensuring reliable system operation.

Technical Specifications

Functional Description

The Woodward 5417-027 NetCon LoDen Analog Cable is designed to ensure the protection and reliability of analog signals. By using the enclosure as a shield termination point, this cable effectively grounds the cable shields. This mechanism safeguards against external electromagnetic interference, preventing any negative effects on signal quality.

This connection preserves the integrity of the signal and ensures a robust and secure grounding system.

The cable offers two primary termination methods: AC (capacitive) and DC. Capacitive termination allows AC signals to be safely grounded, while DC termination establishes a direct electrical connection. Both options ensure effective shielding and reliable signal transmission.

Moreover, proper installation of shield termination hardware is essential. This hardware, typically including connectors or clamps, secures the cable shields and ensures an electrical connection to the cabinet’s structural frame. By following correct installation procedures, the Woodward 5417-027 cable guarantees optimal performance and signal integrity.

Installation Requirements

• Shield Termination Hardware: Install connectors or clamps at cable entry points for secure grounding and effective shield termination.
• Grounding Connection: Use either capacitive or direct DC termination to ground the cable shields.
• Mounting in Enclosure: Secure the cable within the enclosure for optimal protection and grounding effectiveness.

Applications

• Industrial Automation: Ideal for environments where reliable, interference-free signal transmission is crucial.
• Control Systems: Ensures stable operation in complex control systems that depend on analog signal accuracy.
• Power Generation: Used in power plants and related systems to ensure signal integrity amidst electrical interference.
• Signal Processing: Provides dependable signal protection in systems that require precise data transmission.

Why Choose Woodward 5417-027?

• Superior Shielding: The Woodward 5417-027 effectively protects against electromagnetic interference, maintaining high-quality signal transmission.
• Flexible Grounding Options: Choose between AC and DC termination methods for optimal performance.
• Easy Installation: The cable includes simple-to-use termination hardware for quick setup and reliable performance.
• Durable and Reliable: Built to withstand industrial environments, ensuring long-term, hassle-free operation.
