Woodward 5417-039 Speed Sensor Module

Overview

The Woodward 5417-039 speed sensor module provides precise speed measurements for rotating shafts in various industrial applications. By utilizing Hall effect technology, it generates an output voltage directly proportional to the shaft’s rotational speed. Additionally, the module is equipped with a built-in amplifier and filter to ensure high-quality signals, making it reliable even in challenging environments.

Key Features

Hall Effect Sensor: Delivers reliable and accurate speed measurements across different systems.
Built-in Amplifier and Filter: Enhances signal integrity by eliminating noise and improving overall clarity.
Rugged and Durable: The NEMA 4X and IP67 ratings make it resistant to dust, water, and other harsh conditions.
Wide Operating Temperature Range: Withstand temperatures from -40°C to 85°C, making it suitable for diverse industrial environments.
Long Lifespan: Designed to last for over 10 million hours, ensuring minimal maintenance and long-term reliability.

Applications

The Woodward 5417-039 speed sensor module proves useful in various industrial systems. Key applications include:

Engine Speed Measurement
Pump Speed Monitoring
Fan Speed Measurement
Conveyor Belt Speed Control
Machine Tool Spindle Speed Measurement

Technical Specifications

Specification	Details
Part Number	5417-039
Manufacturer	Woodward
Product Type	Speed Sensor Module
Output Voltage	0 to 10 V
Sensitivity	10 mV/(1000 rpm)
Accuracy	±1% of reading
Linearity	+0.5% of full scale
Operating Temperature Range	-40°C to 85°C
Storage Temperature Range	-40°C to 125°C
Dimensions	63 x 30 x 18 mm (2.5 x 1.2 x 0.7 in)
Weight	0.38 kg

Functional Description

The Woodward 5417-039 operates on Hall effect principles, generating a reliable output signal in response to the shaft’s rotation. This sensor offers precise speed measurements even in noisy environments. By using the built-in amplifier and filter, the sensor maintains signal clarity, free from interference, which is crucial for real-time data processing in control systems.

Moreover, this module is built to endure challenging industrial environments. Its NEMA 4X and IP67 ratings ensure that it performs well in dusty, wet, and harsh conditions. Furthermore, its wide temperature range enables it to function in extreme environments, from -40°C to 85°C. This makes the Woodward 5417-039 suitable for a wide array of applications, including engine speed and machine tool spindle speed measurement.

Why Choose the Woodward 5417-039?

Precision and Accuracy: The Hall effect sensor provides highly accurate speed measurements across various systems, ensuring dependable results.
Extended Durability: Thanks to its long lifespan of over 10 million hours, this sensor requires minimal maintenance and provides long-term service.
Robust Performance: Its NEMA 4X and IP67 ratings make it durable in tough industrial settings.
Wide Temperature Range: The sensor is highly versatile, operating effectively from -40°C to 85°C.

Conclusion

In conclusion, the Woodward 5417-039 speed sensor module is a versatile and reliable choice for precise speed measurement in industrial applications. Whether you’re measuring engine speed, pump speed, or machine tool spindle speed, this sensor will deliver accurate and stable performance. Choose the Woodward 5417-039 for robust, long-lasting speed sensing solutions in harsh environments.
