Technical Overview
The 6GK1243-3SA00 communications processor connects SIMATIC S5 controllers to AS-Interface (AS-i) networks. This module enables digital and analog I/O communication over a two-wire cable. It manages up to 31 slave devices with integrated power and data transmission. The onboard processor handles all AS-i protocol tasks autonomously.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model Number | 6GK1243-3SA00 |
| Product Type | Communications Processor |
| Series | SIMATIC S5 / AS-Interface |
| Network Protocol | AS-Interface (AS-i) |
| Max Slave Devices | 31 |
| I/O Data | 4 inputs / 4 outputs per slave |
| Cable Type | Standard AS-i two-wire cable |
| Power | Integrated power supply for AS-i network |
| Data Transfer | Cyclic and acyclic communication |
| Approx. Weight | 0.5 kg |
AS-i Network Architecture
The 6GK1243-3SA00 supports the AS-i master-slave protocol for simple field device integration. It automatically detects and configures connected slave devices upon power-up. This plug-and-play functionality minimizes setup time.
Integrated Power Supply and Cabling
The module provides the necessary power for the entire AS-i network. Standard two-wire cables deliver both communication signals and energy to all slaves. This hybrid approach reduces installation costs.
Application and System Integration
This CP suits low-cost I/O applications requiring minimal wiring. It accepts digital sensors, actuators, and analog modules within the AS-i network. Consequently, maintenance engineers can quickly expand or modify field devices.
