Siemens 6ES7626-1AG01-0AE3 C7-626 Membrane Switch

Integrated Operator Interface for C7-626 Systems

The Siemens 6ES7626-1AG01-0AE3 functions as the membrane switch panel for the SIMATIC C7-626 compact control system . This integrated unit combines an S7-300 CPU (6ES7315-1AF01-0AB0) with an OP25 operator panel in a single housing . The membrane keyboard features 48 keys with metal dome technology, providing tactile feedback and excellent durability . A graphic-capable FSTM display with 360 x 240 pixel resolution supports clear process visualization . The front panel achieves IP65 protection against dust and water jets .

Technical Specifications

Specification	Value
Model	6ES7626-1AG01-0AE3
Product Type	C7-626 Membrane Switch Panel
CPU Type	CPU 315 (6ES7315-1AF01-0AB0)
Display	FSTM graphic, 360 x 240 pixels
Keys	48 keys with metal domes
LED Indicators	28 integrated
Digital Inputs	16
Digital Outputs	16
Analog Inputs	4
Analog Outputs	1
Memory (Work)	128 Kbytes
Memory (Flash)	128 Kbytes
Dimensions (W x H x D)	240 mm x 168 mm x 69 mm
Weight	1.35 kg
Protection (Front)	IP65
Supply Voltage	24 V DC
Current Consumption	1000 mA max
Operating Temp.	0 °C to 45 °C
Backup Battery	Approx. 1 year backup time

Integrated I/O and Programming Capabilities

The Siemens 6ES7626-1AG01-0AE3 integrates substantial I/O capacity directly into the unit, including 16 digital inputs, 16 digital outputs, 4 analog inputs, and 1 analog output . It supports programming in STL, LAD, or FBD via STEP 7, while the operator panel uses ProTool for configuration . The unit features a serial V.24 interface for printer connection and an MPI interface for programming . The membrane keyboard holds a lifespan exceeding 1 million actuations per key, making it suitable for long-term industrial use .
