Siemens 6ES7194-5AA00-0XA0 | ET 200 Cable Connector

The Siemens 6ES7194-5AA00-0XA0 serves as a robust cable connector unit. This component works within the ET 200 distributed I/O system. It ensures reliable signal transmission between field devices and controllers.

Key Technical Specifications

Below you will find the accurate technical parameters for the Siemens 6ES7194-5AA00-0XA0.

Parameter	Specification
Product Type	Cable Connector
Series	ET 200
Connection Type	Push-in termination
Wire Gauge Range	0.25 – 1.5 mm²
Rated Voltage	24 V DC
Rated Current	4 A per contact
Number of Pins	5
Protection Rating	IP20
Manufacturer	Siemens

The connector measures 45 mm in length and 15 mm in width. Its total weight reaches approximately 25 grams. This unit contains five spring-loaded contact pins. Energy storage does not apply to this passive component.

You will find a clear labeling area on the connector housing. The push-in termination allows tool-free wire installation. Therefore, you can complete field wiring very quickly. This design also supports single-wire removal without damage.

Installation and Compatibility

You can use the Siemens 6ES7194-5AA00-0XA0 with all ET 200 interface modules. The connector fits standard 5-pin M12 sockets as well. It requires no additional power supply for operation. The IP20 rating protects against solid objects above 12 mm. Consequently, you should install this connector inside a control cabinet.
