Efficient Power Distribution for the SIMATIC ET 200SP System
The Siemens 6ES7193-6UP00-0BP1 potential distributor module offers a compact and efficient solution for distributing power within your SIMATIC ET 200SP setup. This PotDis-BaseUnit (PotDis-BU type P1) simplifies the creation of potential groups and organizes your control cabinet wiring. Its slim 15 mm width saves valuable space on the DIN rail, which makes it ideal for high-density I/O configurations. The dark-colored unit supports a DC input and output voltage range of 0 to 48 V and has a maximum current-carrying capacity of 10 A for both the P1/P2 bus and the process terminals.
This module provides 17 terminals for the P1 potential and 1 terminal for the P2 potential. It also bridges the P1, P2, and AUX rails to the left BaseUnit, which ensures a continuous power supply across multiple modules. The use of Push-In terminals enables fast, tool-free wiring with conductor cross-sections from 0.14 mm² to 2.5 mm², which significantly reduces installation time. The module features a robust design that withstands challenging conditions, with an operating temperature range from -30 °C to +60 °C (horizontal installation) and supports installation altitudes up to 5,000 meters.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Potential Distributor Module (PotDis-BaseUnit) |
| Model | 6ES7193-6UP00-0BP1 |
| Color | Dark (CC62 color code) |
| Dimensions (W x H x D) | 15 mm x 117 mm x 35 mm |
| Weight | Approx. 40 g |
| Number of Slots | 1 |
| P1 Potential Terminals | 17 |
| P2 Potential Terminals | 1 |
| Input/Output Voltage (DC) | 0 to 48 V |
| Max. Current Carrying Capacity | 10 A |
| Terminal Type | Push-In |
| Conductor Cross-Section | 0.14 mm² to 2.5 mm² |
| Isolation Test Voltage | 3,250 V DC |
| Ambient Temp (Horizontal) | -30 °C to +60 °C |
| Installation Altitude | Up to 5,000 m |
The Siemens 6ES7193-6UP00-0BP1 integrates seamlessly with the ET 200SP distributed I/O system, delivering reliable power distribution across your automation network. Its lightweight construction of approximately 40 g minimizes mechanical strain on the DIN rail, while the compact footprint leaves ample room for additional components. This module supports a wide operating temperature range, making it suitable for demanding industrial environments. Its Push-In terminal technology accommodates conductors from 0.14 mm² to 2.5 mm², which provides flexibility for various wiring needs. The unit’s isolation test voltage of 3,250 V DC ensures safe operation even under high-voltage conditions. For engineers seeking a dependable and space-saving power distribution module, this solution delivers consistent performance and long-term reliability.
