Siemens 6ES7138-4CB10-0AB0 Power Module

Reliable Power Distribution for Distributed I/O Systems

The Siemens 6ES7138-4CB10-0AB0 power module supplies dependable power to the SIMATIC ET 200S distributed I/O system. This module provides the necessary power for the electronic modules and sensors connected to the station. Its compact design fits seamlessly into the ET 200S terminal block. The module features a robust design for industrial environments. It ensures stable operation under varying load conditions. Furthermore, it facilitates straightforward system expansion.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Product Type	Power Module
Part Number	6ES7138-4CB10-0AB0
System	SIMATIC ET 200S
Nominal Input Voltage	24 VDC
Input Voltage Range	20.4 to 28.8 VDC
Output Current (Max)	2 A
Power Loss (Typical)	3 W
Diagnostics	LED display for input power and output status
Dimensions	15 x 60 x 55 mm
Weight	Approx. 0.05 kg
Operating Temperature	0°C to +55°C
Certification	CE, UL, CSA

Robust Design and Diagnostic Capabilities

The Siemens 6ES7138-4CB10-0AB0 offers comprehensive diagnostic features for fault identification. Built-in LEDs display the status of the input power and the outputs. This facilitates rapid troubleshooting. The module also protects against overload and short-circuit events. The module ensures stable operation under varying industrial conditions. Its robust design minimizes the risk of downtime.

System Integration and Expansion

The Siemens 6ES7138-4CB10-0AB0 integrates seamlessly with all ET 200S stations. It powers the backplane bus and supplies power to the electronic modules. This allows for easy system expansion. The module supports a wide range of sensors. It is a crucial component for reliable power distribution. The module enhances the overall reliability of your automation system.
