Siemens 6ES5982-3UA11 Mounting Frame

Why This Mounting Frame Secures Your S5 Rack

This durable mounting frame provides stable support for your SIMATIC S5 components. You get a sturdy Siemens 6ES5982-3UA11 designed for industrial control cabinets. It holds multiple S5 modules in a secure vertical orientation. Therefore, your system maintains proper alignment even under vibration.

Technical Specifications and Physical Details

The Siemens 6ES5982-3UA11 accommodates up to eight S5 series modules. It features pre-drilled holes for easy cabinet mounting. This frame uses cold-rolled steel with a corrosion-resistant coating. Its dimensions measure approximately 482 mm in width and 200 mm in height. The unit weighs around 2.50 kg for stable installation. This mounting frame stores no electrical energy whatsoever. Instead, it serves as a purely mechanical support structure. Consequently, you need no batteries or capacitors for this component.

Below is the detailed breakdown of the hardware specifications.

Parameter	Specification
Product Model	6ES5982-3UA11
Product Type	Mounting Frame
Brand	Siemens
Family	SIMATIC S5
Module Capacity	Up to 8 S5 modules
Material	Cold-rolled steel
Surface Finish	Corrosion-resistant coating
Mounting Type	Screw fixing to cabinet
Dimensions (W x H)	Approx. 482 x 200 mm
Approx. Weight	2.50 kg
Energy Storage	None (passive mechanical part)
Component Count	Single frame assembly

Installation and Integration Notes

This frame mounts directly onto the rear panel of a control cabinet. You must use M6 screws with flat washers for secure attachment. The Siemens 6ES5982-3UA11 accepts standard S5 rails and modules. Therefore, you can slide each card into place without special tools. Always verify that the frame sits level before tightening all bolts. An uneven frame will cause module alignment issues and poor connector contact.
