Siemens 6ES5948-3UR13 | SIMATIC S5 Processor Module

Technical Overview of the Processor Module

The Siemens 6ES5948-3UR13 serves as the central processing unit for high-performance SIMATIC S5 automation tasks. This module executes complex user programs with enhanced speed and precision. It manages extensive I/O configurations and communication responsibilities efficiently. The design features additional memory and advanced instruction handling.

Key Technical Specifications

This section lists the precise parameters for the Siemens 6ES5948-3UR13 processor module. Use these figures to confirm compatibility with your automation requirements.

Parameter	Specification
Part Number	6ES5948-3UR13
Type	Processor Module / CPU
Product Family	SIMATIC S5
User Memory	48 Kbytes (RAM, expandable)
Programming Languages	Ladder Logic, Statement List, CSF
I/O Capacity	Up to 1024 digital I/O points
Processing Speed	Approx. 5 ms per 1K instructions
Communication Ports	1x RS232 (PG interface), 1x RS485
Real-time Clock	Integrated with battery backup
Dimensions (W x H x D)	Approx. 250 x 25 x 180 mm
Weight	Approx. 1.4 kg
Compatibility	SIMATIC S5-135U and 155U systems

Application and System Integration

This processor module fits directly into the S5-135U or 155U rack. It executes control logic for large-scale automation processes efficiently. The Siemens 6ES5948-3UR13 supports up to 1024 digital I/O points. Its integrated RS485 port enables multi-controller networking. Consequently, engineers can implement complex distributed systems with this CPU.

Reliability and Performance Advantages

The module handles intensive arithmetic and data processing with minimal cycle times. Its larger memory accommodates sophisticated programs and data tables. The rugged construction ensures dependable operation in harsh factory environments. System designers select the Siemens 6ES5948-3UR13 for its high-performance capabilities.
