Siemens 6ES5463-4UA13 Analog Input Module

This analog input module converts field sensor signals into digital values for SIMATIC S5. It handles voltage and current measurements from transmitters and sensors. Therefore, this component suits temperature, pressure, and flow monitoring applications.

Physical Dimensions and Weight Specifications

The Siemens 6ES5463-4UA13 occupies one standard slot in the S5 rack. Its housing measures 233 mm in depth for backplane connectivity. The module weighs approximately 0.52 kg for straightforward handling. Consequently, technicians can install this unit without additional rack reinforcement.

Interface Types and Connection Layout

The Siemens 6ES5463-4UA13 provides a 48-pin front connector for sensor wiring. A second 20-pin backplane connector supplies power and data to the CPU. The front panel carries LED indicators for each active channel. Hence, operators can monitor signal status at a quick glance.

Component Count and Channel Configuration

This analog input module contains one main board with four differential input channels. Each channel uses a 12-bit analog-to-digital converter for signal conversion. You will also find a programmable gain amplifier for range selection. An onboard precision voltage reference ensures accurate measurements across temperature changes.

Energy Storage and Power Consumption

The Siemens 6ES5463-4UA13 draws 130 mA from the 5V backplane supply. It also requires 70 mA from a 24V external supply for analog circuits. A small capacitor bank filters noise on the analog power rail. This storage reduces measurement errors from power supply fluctuations.

Measurement Accuracy and Signal Processing

The module achieves a measurement accuracy of ±0.2% over full scale. It samples all four channels sequentially within a 12 ms cycle. Users can configure each channel independently via software jumpers. This flexibility supports mixed sensor types within a single module.
