Siemens 6ES5398-0DE13 Operator Panel

Technical Overview

The Siemens 6ES5398-0DE13 is a compact operator panel designed for the SIMATIC S5 programmable controller series. This unit provides a user-friendly interface for monitoring and controlling industrial processes. It features a 4-line display and membrane keypad for data entry and system navigation. The panel includes serial communication ports for connecting to the PLC programming interface.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Model Number	6ES5398-0DE13
Product Type	Operator Panel
System Compatibility	SIMATIC S5
Display Type	LCD (4-line)
Display Format	4 lines x 20 characters
Keypad Type	Membrane
Communication Interface	Serial (programming device port)
Power Supply	24 VDC
Power Consumption	5 W (typical)
Dimensions	120 x 120 x 45 mm
Weight	0.35 kg
Operating Temperature	0°C to +50°C
Storage Temperature	-20°C to +70°C
Humidity	5% to 95% RH (non-condensing)
Protection Rating	IP40 (front panel)
Certifications	CE, UL, CSA
Country of Origin	Germany

Key Features

Compact Panel Design – The small footprint fits easily into control cabinets and machine consoles.

4-Line LCD Display – The clear alphanumeric display presents process data and system messages.

Membrane Keypad – The tactile keypad enables straightforward data entry and menu navigation.

Serial Communication – The interface provides reliable connection to the S5 programming port.

Low Power Consumption – The panel draws only 5W, reducing heat generation in control cabinets.

Applications

The Siemens 6ES5398-0DE13 suits machine-level control, process monitoring, and system diagnostics in manufacturing environments. It provides a clear interface for operators to interact with S5-based automation systems.
