Siemens 6ES5247-4UA41 PLC Module

The Siemens 6ES5247-4UA41 PLC Module provides high-speed counting functions for SIMATIC S5 systems. This module processes encoder signals and frequency measurements. You will find it in positioning and velocity monitoring applications. It accepts up to two incremental encoder inputs for precise motion control. Therefore, this unit suits cut-to-length machines and conveyor tracking systems.

The Siemens 6ES5247-4UA41 PLC Module measures 230 mm in height and 48 mm in width. Its depth reaches 180 mm for standard rack mounting. The unit weighs approximately 0.64 kilograms. It contains one 32-bit counter and two input channels. Four digital outputs provide setpoint switching capability. Additionally, you get six status LEDs for diagnostics.

Key Technical Specifications

Parameter	Value
Manufacturer	Siemens AG
Model	6ES5247-4UA41
Product Type	PLC Module
Counter Channels	2 (incremental encoder)
Counter Resolution	32 bits
Maximum Frequency	100 kHz per channel
Input Types	5 V differential, 24 V DC
Digital Outputs	4 (24 VDC, 0.5A)
Count Modes	Up/down, quadrature, pulse/direction
Height	230 mm
Width	48 mm
Depth	180 mm
Weight	0.64 kg
Status LEDs	6 (PWR, CNT0, CNT1, OUT)
Energy Storage	≈ 240 µF (capacitive)
Power Consumption	230 mA @ 5 VDC
Encoder Supply	5 VDC (300 mA)
Operating Temperature	0°C to +60°C
Mounting Method	S5 rack

Internal Architecture and Energy Storage

The Siemens 6ES5247-4UA41 PLC Module stores minimal energy in its power filter. Small electrolytic capacitors hold approximately 240 microfarads total capacitance. A 32-bit hardware counter processes encoder pulses without CPU intervention. This counter supports quadrature decoding for x1, x2, or x4 multiplication. Two input channels accept both 5 V differential and 24 V DC signals. The module provides a regulated 5 VDC output to power encoders. Four digital outputs switch loads based on programmable setpoints. Four optocouplers isolate the outputs from the logic circuits. Six LEDs show power, counter activity, and output status clearly.

Connection Interfaces and Wiring Details

You will find a 20-pin removable terminal block on the bottom face. The Siemens 6ES5247-4UA41 PLC Module also provides 5 VDC encoder power on terminals 7 and 8. Connect the four digital outputs to terminals 9 through 16. Use shielded twisted-pair cable for all encoder connections. Connect the shield drain wire to the ground terminal. Six LEDs indicate power, counter activity, and output status. A green CNT0 LED flashes during encoder pulses on channel 0. A yellow OUT0 LED lights up when the first setpoint output activates.

Configuration and Installation Steps

You slide this module into any I/O slot of the SIMATIC S5 rack. First, align the module with the upper and lower card guides. Then, push it firmly until the backplane connector seats completely. Secure the front panel with the two retaining screws. Connect all encoder and output wiring before applying power. The Siemens 6ES5247-4UA41 PLC Module requires an external 24 VDC supply for outputs. Use the STEP 5 software to configure count mode and multiplication factor. Set the comparison values for each digital output. Download the configuration to the module’s internal memory. Test the encoder with manual rotation before system startup.
