The Siemens 6AV3503-1DB10 OP 3 Operator Panel offers an intuitive and reliable interface for your SIMATIC S7 PLC systems. It allows users to quickly monitor and control automated processes with ease. Equipped with a graphics-enabled display and a customizable membrane keyboard, this panel enhances both usability and flexibility in demanding industrial environments.
Key Features of the 6AV3503-1DB10 OP 3 Operator Panel:
- High-Resolution Graphics LCD: The 6AV3503-1DB10 uses a graphics-enabled LCD to provide clear, easy-to-read displays. This feature ensures you can view all necessary data with high clarity.
- 2-Line Display with 20 Characters per Line: The panel’s 2-line display accommodates up to 20 characters per line. This setup ensures users can monitor multiple data points at once, improving system efficiency.
- Long-Lasting Backlighting: Designed for industrial environments, the backlighting offers a minimum MTBF of 200,000 hours at 25°C, ensuring a long operational lifespan and reducing the need for frequent maintenance.
- Customizable Membrane Keyboard: The membrane keyboard is user-definable, allowing you to label the keys for specific tasks. This feature improves workflow and simplifies operator control.
- 5 Programmable Function Keys: The panel includes 5 programmable function keys, giving users quick access to frequently used operations for improved workflow and efficiency.
- Complete Cable Set Included: The 6AV3503-1DB10 comes with cables for connecting to SIMATIC S7 systems, simplifying installation and configuration.
Specifications:
| Feature | Specification |
|---|---|
| Model | 6AV3503-1DB10 |
| Type | OP 3 Operator Panel |
| Display Type | Graphics-enabled LC display |
| Color Type | Black/White |
| Number of Lines | 2 |
| Number of Characters per Line | 20 |
| Backlighting MTBF | 200,000 hours at 25°C |
| Keyboard Type | Membrane keyboard, user-definable labels |
| Function Keys | 5 function keys |
| Cable Set | For power supply and configuration |
| Dimensions | 150 x 120 x 40 mm |
| Weight | 0.6 kg |
| Operating Temperature | 0°C to +50°C |
| Mounting Type | Panel mounting |
Benefits:
- Enhanced Usability: The 6AV3503-1DB10 ensures easy operation with its clear display and customizable keyboard, minimizing operator training time.
- Long-Term Durability: With backlighting rated at 200,000 hours, the panel operates reliably over time. You can count on it for consistent performance in demanding environments.
- Customizable Control: The customizable membrane keyboard and function keys allow you to personalize the interface, making it easier to access the controls you need.
- Simple Installation: The included cable set provides everything you need for quick and straightforward integration with SIMATIC S7 PLC systems.
Applications:
The Siemens 6AV3503-1DB10 OP 3 Operator Panel is ideal for a wide range of industrial applications:
- SIMATIC S7 Systems: It serves as a direct interface for SIMATIC S7 PLC systems, ensuring smooth control and monitoring of automated processes.
- Process Automation: The panel enables precise monitoring and control of various industrial processes, improving productivity and reducing downtime.
- Machine Control: Use this panel for controlling machines in industrial settings, where accurate data display and quick control access are essential.
- Manufacturing Automation: The 6AV3503-1DB10 is perfect for manufacturing automation systems, providing operators with an easy interface for monitoring equipment.
Conclusion:
The Siemens 6AV3503-1DB10 OP 3 Operator Panel offers a reliable and efficient solution for managing SIMATIC S7 PLC systems. With its graphics-enabled display, customizable membrane keyboard, and long-lasting backlighting, it ensures seamless integration and optimal system control. Whether for process automation, machine control, or manufacturing applications, this operator panel enhances efficiency and system performance.
