Siemens 6AV1142-1DA10 Text Memory

Engineered for SIMATIC HDI Operator Panel Messages

This module stores alarm and status text messages for operator panels. It provides message storage for the Siemens 6AV1142-1DA10 unit. You will find this text memory card in SIMATIC HDI systems. Unlike standard memory modules, this version holds pre-formatted text strings. It stores up to 2000 individual messages for operator display.

Technical Specifications & Physical Dimensions

We designed this text memory module for industrial operator interface applications. The table below presents all verified technical specifications.

Parameter	Specification
Physical Dimensions (W x H x D)	160mm x 125mm x 45mm
Total Weight	0.48 kg (480 grams)
Memory Capacity	32 KB (256 Kbit)
Maximum Messages	2000 text strings
Characters per Message	32 characters maximum
Memory Type	EPROM (UV-erasable)
Operating Voltage	5V DC (from backplane)

Functional Architecture and Message Retrieval

This text memory connects directly to the HDI operator panel. It stores pre-programmed text for alarms and status conditions. You can recall each message using a numeric index. Moreover, the module includes fast access circuitry for instant retrieval. This component delivers text within 1 microsecond of request. Consequently, the operator panel displays alarm messages without noticeable delay.

Installation and Operational Guidelines

The Siemens 6AV1142-1DA10 retains all text data for over 20 years. It requires a UV eraser and EPROM programmer for updates. You must align pin 1 with the socket marker carefully. Always cover the quartz window with an opaque label after programming. This practice prevents accidental erasure from ambient light. Furthermore, the module supports message chaining for multi-line displays. This feature combines several messages into one screen.

Physical Characteristics and Environmental Limits
