Schneider XBTP021010 Operator Interface Terminal

This operator interface terminal provides touchscreen control for industrial machinery and processes. It displays machine status and accepts operator commands through an intuitive interface. You can deploy this unit for local monitoring and control in factory automation.

Technical Specifications

Parameter	Value
Model	Schneider XBTP021010
Category	Operator Interface Terminal
Display Type	3.5-inch TFT LCD
Display Resolution	320 × 240 pixels (QVGA)
Display Colors	256 colors from 64K palette
Touch Technology	Analog resistive touchscreen
Backlight Type	LED (white)
Backlight Life	50,000 hours typical
Communication Ports	1 × RS-232, 1 × RS-485 (non-isolated)
Protocol Support	Modbus RTU master/slave, Uni-TE
USB Port	1 × USB 2.0 (mini-B, programming only)
Memory	8 MB Flash (application), 1 MB SRAM
Real-Time Clock	Yes (with capacitor backup)
Power Input	24 VDC ±20%, 5 W typical
Dimensions (W x H x D)	10.5 cm × 8.5 cm × 4.5 cm
Weight	0.32 kg (0.71 lbs)
Connector Type	1 × 9-pin D-sub + 1 × 5-pin terminal + 1 × USB
Component Count	1 main board + 1 LCD + 1 touchscreen + 1 backlight + 1 LED
Energy Storage	Supercapacitor for RTC backup (14 days)
Enclosure Rating	IP65 (front panel when properly mounted)
Operating Temperature	0°C to 50°C

Display and User Interface

The Schneider XBTP021010 features a 3.5-inch TFT screen with 256 colors. A resistive touchscreen registers input even when you wear work gloves. The LED backlight provides up to 50,000 hours of continuous operation. Therefore, this terminal lasts for years without display degradation.

Communication Connectivity

One RS-232 port connects directly to a single PLC or programming PC. A separate RS-485 port supports Modbus RTU networking on the factory floor. The terminal acts as a Modbus master to poll data from multiple slaves. Consequently, you can monitor and control several devices from one terminal.

Memory and Application Storage

This unit provides 8 MB of Flash memory for storing application screens and logic. An additional 1 MB of SRAM holds runtime variables and alarm history. The total application size can reach up to 1,000 screens in typical projects. Therefore, this terminal suits small to medium machine applications comfortably.

Real-Time Clock and Data Backup

A supercapacitor maintains the real-time clock for up to 14 days without external power. The RTC enables time-stamped alarms and production data logging. You can synchronize the terminal clock with a central PLC for consistency. Consequently, event logs show accurate timing for troubleshooting and reporting.

Installation and Mounting

Mount this terminal into a standard panel cutout of 93 mm × 73 mm. The front panel meets IP65 rating when you properly seal the gasket. Four mounting clips secure the unit without requiring any special tools. For best results, avoid direct sunlight and heat sources above 50°C.

Programming and Configuration

You need Schneider Vijeo Designer software to create applications for this terminal. The software supports multi-language text, bitmaps, and vector graphics. You can download applications through either the RS-232 port or USB port. Therefore, no special programming cable is needed for this device.

Why Choose This Terminal

This compact HMI fits perfectly into small machine panels with limited space. Its 3.5-inch screen provides adequate visibility while saving valuable panel real estate. Therefore, manufacturers choose this unit for packaging equipment, conveyors, and small assembly stations.
