Schneider XBTH011010 Switch Keypad | 10 Keys

User Interface for Industrial Control Panels

The Schneider XBTH011010 provides a reliable operator interface for industrial machinery. This switch keypad allows users to input commands and control machine functions. It suits conveyor systems, packaging lines, and material handling equipment.

Technical Specifications

Parameter	Specification
Model	XBTH011010
Category	Switch Keypad
Height	72 mm
Width	72 mm
Depth	47 mm
Weight	0.130 kg
Number of Keys	10 (arranged 2 x 5)
Key Type	Tactile membrane with embossed surface
Key Material	Polyester (UV and chemical resistant)
Key Life	1 million actuations minimum
Operating Force	3.5 N ±0.5 N per key
Key Travel	1.2 mm
Contact Configuration	Normally open (momentary)
Contact Material	Silver-plated nickel
Switching Voltage	24 V DC max
Switching Current	10 mA to 50 mA
Contact Resistance	<10 Ω initial
Insulation Resistance	>100 MΩ at 500 V DC
Dielectric Strength	500 V RMS for 1 minute
Connector Type	1 x 14-pin ribbon cable (200mm length)
Backlighting	None (non-illuminated)
Protection Rating	IP65 (front panel)
Internal Components	10 membrane contacts, 1 connector cable, 1 adhesive gasket
Energy Storage	None (no battery or capacitor)

Keypad Architecture and Tactile Feedback

The XBTH011010 features ten tactile membrane keys arranged in two columns. Each key provides a distinct embossed surface for finger positioning. The keypad delivers 3.5 newtons of operating force with 1.2mm travel. You feel a clear tactile click upon each key actuation. The Schneider XBTH011010 uses silver-plated nickel contacts for reliable switching. Each normally open contact closes momentarily while you press the key.

Durability and Environmental Protection

This switch keypad withstands one million actuations under normal use. The polyester membrane resists UV exposure, oils, and industrial chemicals. The XBTH011010 achieves IP65 protection rating from the front panel. This rating keeps dust and water jets away from internal electronics. A silicone rubber gasket seals the keypad to the mounting panel. The rear electronics remain protected in humid or washdown environments.

Electrical Characteristics and Wiring

The Schneider XBTH011010 switches 24 V DC signals at 10 to 50 milliamperes. Initial contact resistance measures below 10 ohms for low-voltage applications. Insulation resistance exceeds 100 megohms at 500 V DC. A 200mm ribbon cable with 14-pin connector attaches to the PCB. The XBTH011010 includes a common row and column matrix arrangement. This matrix reduces the number of required input wires significantly.

Physical Dimensions and Panel Mounting

The Schneider XBTH011010 weighs only 0.130 kilograms for lightweight installation. Its height measures 72mm, width 72mm, and depth 47mm. Cut a 68mm x 68mm square hole in the control panel. Mount the keypad using four M3 screws through the corner holes. The unit operates reliably from -20°C to +70°C ambient temperature. Do not exceed 85% relative humidity (non-condensing) for safe operation.

Energy Storage and Passive Operation

The XBTH011010 stores no electrical energy internally. It contains zero batteries or capacitors of any kind. Hence, this switch keypad requires no periodic maintenance whatsoever. You will never replace batteries or perform discharge procedures. The Schneider XBTH011010 consumes no power when idle. It only draws current during the brief moment of key actuation.
