Schneider TSXPSY5520MC Power Supply Module

Technical Overview of This Rack Power Source

The Schneider TSXPSY5520MC provides clean DC power to your PLC rack. This power supply module belongs to the Modicon Premium TSX series from Schneider Electric. It converts AC mains into regulated voltages for backplane operation. Consequently, all connected I/O and CPU modules receive stable power.

Hardware Specifications and Design Details

This power supply module weighs approximately 0.9 kg. Its compact dimensions are 130 mm in height, 80 mm in width, and 160 mm in depth. The Schneider TSXPSY5520MC features a single screw terminal block for AC input. It supplies 5 V DC and 24 V DC to the backplane bus. The module contains one internal transformer and multiple filtering capacitors. It stores limited energy in its output capacitors for short hold-up time. Therefore, the module maintains output for approximately 15 milliseconds during power interruptions.

Parameter	Specification
Manufacturer	Schneider Electric
Model	TSXPSY5520MC
Category	Power Supply Module
Series	Modicon Premium TSX
Input Voltage	100 V to 240 V AC (single-phase)
Input Frequency	50 Hz / 60 Hz
Output Voltage	5 V DC and 24 V DC
Output Power	55 W maximum
Weight	0.9 kg (1.98 lbs)
Dimensions (H x W x D)	130 x 80 x 160 mm
Interface	Screw terminal block (AC input)
Number of Components	Transformer, rectifier, filter capacitors
Energy Storage	Output capacitors (15 ms hold-up)
Mounting	Rack-mounted in TSX Premium chassis
Efficiency	Approximately 82%

Installation and Operation Guidelines

You can install the Schneider TSXPSY5520MC in the leftmost rack slot. It connects directly to the Premium backplane via a dedicated connector. Furthermore, the module provides overvoltage and short-circuit protection internally. Always use a proper circuit breaker on the AC input line. This practice safeguards the power supply from severe electrical faults.
