Schneider TSXP57353M | Modicon Premium Processor

The TSXP57353M serves as the central processing unit for Premium automation systems. This processor executes user logic and manages all I/O communication tasks efficiently. It provides a solid foundation for mid-sized to large control applications. Consequently, you get reliable performance for complex machine control sequences.

You can program this processor using the Unity Pro software environment. The TSXP57353M supports all five IEC 61131-3 programming languages. These include ST, IL, LD, FBD, and SFC. Therefore, engineers can choose their preferred language for each project.

Memory Architecture and Data Storage

The processor incorporates significant memory resources for user programs. The TSXP57353M provides 512 KB of RAM for logic and data storage. An additional 32 KB of flash memory retains the application safely. This flash storage holds the program even after a complete power loss.

A supercapacitor provides backup power for the real-time clock. This energy storage maintains the date and time for approximately 30 days. The TSXP57353M does not require any user-replaceable battery for this function. Below is a complete breakdown of its technical characteristics.

Specification	Detail
Product Type	Premium P57 Processor
User Program Memory	512 KB RAM (Battery-backed)
Flash Memory	32 KB (Non-volatile)
Processing Speed	0.10 ms per 1K of ST instructions
Local I/O Capacity	1024 digital / 256 analog
Remote I/O Capacity	Up to 8 racks via Fipio
Execution Base	10 x 10 x 10 (Multitasking)
Dimensions (W x H x D)	40 mm x 100 mm x 95 mm
Weight	0.34 kg (340 grams)
Power Consumption (5V)	550 mA
Energy Storage	Supercapacitor (30 days for RTC)

Interface Layout and Connectivity Options

The processor includes a built-in USB port for programming connections. The TSXP57353M also features a serial RS-485 interface for Modbus communication. A 9-pin D-sub connector provides the physical link for the programming terminal. One rotary switch selects the node address on the Fipio bus.

Two LEDs on the front panel indicate RUN and ERR status clearly. The TSXP57353M also includes a memory card slot for additional storage. This slot accepts PCMCIA memory cards for program backup. Therefore, you can transfer programs without a programming computer.

Operational Benefits for Control Applications

This processor handles demanding automation tasks with consistent performance. The TSXP57353M supports up to 8 axes of motion control integration. It also manages multiple communication protocols simultaneously without slowing down. Engineers trust this module for critical manufacturing and infrastructure applications.
