Schneider TSXP571634M Unity Processor

The TSXP571634M delivers advanced processing power for Modicon Premium control systems. This Schneider Electric unit runs Unity Pro software for sophisticated automation applications. We engineered this processor to handle complex logic, motion control, and process management tasks.

Technical Specifications and Design Features

This Unity processor weighs approximately 0.55 kilograms. Its dimensions measure 130 millimeters in height, 70 millimeters in width, and 140 millimeters in depth. The unit features a robust plastic housing with integrated heat dissipation for reliable operation.

Parameter	Specification
Manufacturer	Schneider Electric
Model	TSXP571634M
Category	Unity Processor Module
Product Line	Modicon Premium
Processor Type	32-bit RISC
Memory	2 MB RAM, 1 MB Flash
Processing Speed	0.12 µs per instruction
I/O Capacity	2048 digital, 512 analog
Programming Software	Unity Pro
Communication Ports	2 x Modbus RS-485, 1 x Ethernet
Backup Battery	Lithium 3V (integrated)
Operating Temperature	0°C to 60°C
Dimensions (H x W x D)	130 mm x 70 mm x 140 mm
Weight	0.55 kg

Engineers will value the substantial memory capacity within the TSXP571634M. This processor provides 2 megabytes of RAM for program execution and data handling. An additional 1 megabyte of flash memory securely stores applications during power cycles.

Furthermore, the integrated Ethernet port enables seamless network connectivity. This port supports Modbus TCP/IP for communication with supervisory systems and remote I/O. Consequently, the TSXP571634M fits perfectly into modern industrial Internet of Things architectures.

Energy Storage and Data Integrity

The TSXP571634M includes a lithium 3V backup battery for critical data preservation. This battery maintains program integrity and real-time clock accuracy during power interruptions. Engineers can trust this energy storage to protect valuable application data in the field.

Programming Environment and System Integration

You can program this processor using Schneider Electric Unity Pro software. The TSXP571634M supports all five IEC 61131-3 programming languages. This flexibility allows developers to choose the optimal approach for each control task.

The processor manages up to 2048 digital I/O points and 512 analog channels. This scalability makes it ideal for complex automation projects across various industries. For reference, other Modicon Premium components share this same backplane architecture with the TSXP571634M.

Performance Metrics and Reliability

This unit executes instructions in just 0.12 microseconds per operation. Consequently, it handles high-speed motion control, fast logic scanning, and time-critical processes with exceptional precision. The TSXP571634M includes comprehensive diagnostic LEDs for power, run, Ethernet activity, and communication status.
