Schneider TSXAMZ600 Analogue Module

Overview

The Schneider TSXAMZ600 Analogue Module provides precise signal acquisition and control for industrial automation systems. It features four analogue inputs and two outputs, supporting RMS-TSG-TZ-C series PLC integration for modular control applications.

Key Features

Offers four analogue inputs for accurate voltage or current signal measurement.
Provides two analogue outputs to control industrial actuators and process devices.
Compact module design ensures easy installation in standard PLC racks.
Fully compatible with Schneider RMS-TSG-TZ-C series modules for flexible automation setups.

Technical Specifications

Parameter	Details
Manufacturer	Schneider Electric
Model	TSXAMZ600
Series	RMS-TSG-TZ-C
Category	Analogue Input/Output Module
Analogue Inputs	4 channels (0–10 V / 0–20 mA)
Analogue Outputs	2 channels (0–10 V / 0–20 mA)
Input Impedance	10 kΩ (voltage), 250 Ω (current)
Output Load Capacity	500 Ω maximum
Resolution	12-bit
Accuracy	±0.5%
Response Time	10 ms typical
Dimensions (HxWxD)	6.0 x 3.2 x 1.8 in (152 x 82 x 46 mm)
Weight	0.55 lb (0.25 kg)
Power Supply	24 VDC
Operating Temperature	0°C to 60°C
Mounting Type	Rack mount / PLC slot
Certifications	CE, UL, RoHS compliant

Applications

Schneider TSXAMZ600 is ideal for a variety of industrial automation tasks:

Capturing analogue signals from sensors and process measurement devices.
Controlling actuators, valves, and motors in RMS-TSG-TZ-C series PLC systems.
Enabling precise process monitoring, data acquisition, and modular PLC expansion.

Advantages

Improves system accuracy with high-resolution 12-bit analogue conversion.
Reduces installation time with compact rack-mount design compatible with standard PLC systems.
Ensures reliable operation across industrial temperature ranges and RMS-TSG-TZ-C module configurations.
