Schneider TSX1712028 PLC Module

The Schneider TSX1712028 is a robust PLC module from Schneider Electric’s Modicon series, designed for versatile control in industrial automation. This module offers reliable performance across a range of applications, thanks to its wide operating voltage range and compact design.

Key Features:

Voltage Supply: Operates efficiently within a range of 110-240 V AC.
Compact Design: Measures 17.0 cm in height and 16.5 cm in width.
I/O Capacity: Handles 20 I/O connections (Relay) for flexible control applications.
Environmental Suitability: Supports an operating temperature range from 0°C to 40°C.
Humidity Resistance: Can operate in environments with up to 90% RH (non-condensing).
Protection Rating: Features IP 24 protection, safeguarding against dust and water ingress.
Connectivity: Equipped with screw-type terminal connections for easy installation.

Technical Specifications:

Specification	Details
Manufacturer	Schneider Electric
Product Line	Modicon
Part Number	TSX1712028
Weight	1.05 kg (2.31 lbs)
Type	PLC Module
Power Supply Voltage	110-240 V AC
I/O Connections	20 I/O (Relay)
Operating Temperature Range	0°C to 40°C
Humidity	90% RH (non-condensing)
Protection Rating	IP 24
Terminal Connection Type	Screw (Threaded)
Indicator LEDs	Yes
Alarm	Yes

Description:

The Schneider TSX1712028 PLC module offers excellent flexibility for controlling industrial processes. This module works within the 110-240 V AC power supply range, making it suitable for different industrial automation systems. It includes 20 relay input/output connections, allowing for comprehensive control capabilities in various settings.

With a compact size of 17.0 cm (height) by 16.5 cm (width), the module is designed for easy integration into systems without consuming too much space. Weighing 1.05 kg (2.31 lbs), it’s lightweight yet durable.

This module operates efficiently in environments with a temperature range from 0°C to 40°C and humidity levels up to 90% RH (non-condensing). The IP 24 protection rating ensures that it remains safe from dust and water in demanding industrial conditions. Additionally, the Schneider TSX1712028 is equipped with LED indicators and an alarm, providing real-time system status and notifications for ease of maintenance.

The Schneider TSX1712028 PLC module is an ideal solution for those looking for a reliable, versatile control system for their automation needs.
