Schneider TSX CPPACC1 Electric I/O Module

High-Performance Electric I/O Modules for Industrial Automation

The Schneider TSX CPPACC1 is an advanced Electric I/O module, specifically designed for seamless integration into industrial automation systems. This module facilitates efficient communication and reliable signal processing. It is an ideal choice for environments that demand precision and high performance.

Technical Specifications for Schneider TSX CPPACC1**

Specification	Details
Manufacturer	Schneider Electric
Product Type	Electric I/O Module
Part Number	TSX CPPACC1
Product Line	Modicon TSX Series
Weight	0.68 kg (1.5 lbs)
Input/Output Channels	8 Input/Output Channels
Voltage Range	24 V DC ± 20%
Communication Interface	Modbus TCP/IP, Modbus RTU
Operating Temperature	-10°C to 60°C
Storage Temperature	-40°C to 85°C
Humidity	95% RH (Non-Condensing)
Mounting Type	DIN Rail Mountable
Response Time	< 10 ms
Power Consumption	0.5 A @ 24 V DC
Certification	CE, UL, RoHS

Key Features of the Schneider TSX CPPACC1**

Efficient I/O Capacity: The Schneider TSX CPPACC1 provides 8 I/O channels, ensuring efficient signal processing for diverse industrial systems. It is perfect for applications that require quick data transmission and processing.
Compact, Durable Design: Weighing just 0.68 kg, this module is compact and easy to install in tight spaces. Its robust design guarantees a long operational life in demanding environments.
Wide Voltage Range: Operating within a 24 V DC ± 20% voltage range, the TSX CPPACC1 offers high flexibility for use in various industrial setups. It ensures a stable and reliable performance across different electrical conditions.
Flexible Communication Interfaces: This module supports Modbus TCP/IP and Modbus RTU, two widely used communication protocols. It allows smooth integration into existing industrial networks, enhancing system interoperability.
Fast Response Time: With a response time of less than 10 ms, the TSX CPPACC1 processes data rapidly, ensuring that your industrial automation system operates at maximum efficiency.
Wide Temperature Tolerance: Designed to perform in extreme conditions, this module operates effectively between -10°C to 60°C. Additionally, it can withstand storage temperatures as low as -40°C and as high as 85°C.
Humidity Resistance: The TSX CPPACC1 operates reliably in environments with up to 95% RH (non-condensing), making it suitable for a wide range of industrial settings.
Easy Installation: The DIN rail mounting feature makes installation quick and simple. You can easily integrate the module into your existing control system without complications.

Applications

The Schneider TSX CPPACC1 Electric I/O module is ideal for applications in manufacturing plants, process control systems, and building automation systems. It offers fast, reliable signal processing and enhances the communication capabilities of any industrial automation setup.
