Schneider MA-0186-100 Coaxial Cable Splitter

Overview

The Schneider MA-0186-100 is a high-performance coaxial cable splitter from the I/O Modules series. This compact and efficient repeater is designed to duplicate signals from a single coaxial connection, allowing seamless use of two cables in a ring topology. Ideal for various industrial applications, it provides reliable signal transmission while ensuring minimal space usage and easy integration into existing systems.

Key Features

• Signal Repeater: The MA-0186-100 duplicates a signal from one coaxial cable, supporting the use of two cables in a ring topology.
• Compact Design: With dimensions of 1.18 inches in height, 3.35 inches in width, and 7.05 inches in length, this splitter offers a space-efficient solution for installations with limited space.
• Lightweight Construction: Weighing only 0.13 lbs (0.06 kg), the module is easy to handle and install without compromising durability.
• Sustainability: The module is mercury-free, ensuring a more environmentally friendly product. It also complies with the EU RoHS Directive, guaranteeing it meets strict environmental standards.
• Humidity and Shock Resistance: It operates effectively in environments with 5% to 95% non-condensing humidity, offering reliable performance under varying conditions. Additionally, it can withstand 15 g shock forces and 1 g vibration, making it durable in harsh environments.
• IP68 Protection: With an IP68 rating, the MA-0186-100 is fully protected against dust and water, making it suitable for challenging environments where reliability is critical.

Technical Specifications

Product Description

The Schneider MA-0186-100 coaxial cable splitter is a versatile and compact repeater designed to enhance signal transmission in ring topologies. It efficiently duplicates signals from a single coaxial cable, allowing for the use of two cables, making it a valuable tool for a variety of industrial communication applications.

Measuring just 1.18 inches in height, 3.35 inches in width, and 7.05 inches in length, the module is small enough to fit into tight spaces while delivering reliable performance. Despite its compact size, it weighs only 0.13 lbs (0.06 kg), ensuring ease of installation without sacrificing durability.

Engineered with environmental responsibility in mind, the MA-0186-100 is mercury-free and fully compliant with the EU RoHS Directive, making it an eco-friendly choice. It also performs reliably in a wide range of environmental conditions, tolerating humidity levels between 5% and 95% without condensation.

Built for durability, the module can withstand up to 15 g shock forces and 1 g vibration, ensuring it continues to operate in harsh, high-stress environments. The IP68 rating further enhances its protection against dust and water, ensuring that the splitter remains functional in challenging industrial settings.

Applications

• Industrial Communication: Ideal for use in industrial automation systems, where reliable signal transmission in ring topologies is essential.
• Harsh Environments: The IP68 protection and robust build make this splitter suitable for applications in environments exposed to dust, water, and extreme vibrations.
• Eco-Friendly Systems: Compliant with the EU RoHS Directive, this product is perfect for sustainable automation systems.

Conclusion

The Schneider MA-0186-100 coaxial cable splitter provides a reliable and durable solution for signal duplication in ring topologies. With its compact design, sustainability features, and rugged construction, this repeater ensures high performance across a range of industrial environments. Whether used in challenging conditions or for environmentally-conscious installations, the MA-0186-100 guarantees reliable and efficient operation.
