Schneider Electric TSXDSZ32T5 Analog Input Expansion Module

Product Overview

The TSXDSZ32T5 from Schneider Electric is an advanced analog input expansion module within the Modicon TSX Micro series. This module efficiently converts analog signals from various sensors into digital signals, making it compatible with PLC systems for processing and control.

Key Features and Specifications

• Manufacturer: Schneider Electric
• Product Type: Analog Input Expansion Module
• Product Line: Modicon TSX Micro
• Part Number: TSXDSZ32T5
• Number of Channels: 8 analog voltage inputs
• Input Voltage Range: 0 to 10 V
• Resolution: 12 bits
• Conversion Time: 10 µs per input
• Operating Temperature: -10°C to +55°C
• Storage Temperature: -40°C to +85°C
• Weight: 0.85 kg
• Mounting Type: DIN Rail

Detailed Description

The TSXDSZ32T5 is designed for precise signal conversion and efficient data processing. With 8 analog voltage inputs, it allows simultaneous processing of multiple sensor signals. This is particularly useful for applications that require data from various sensors, such as temperature, pressure, or flow sensors.

It operates within a 0 to 10 V input voltage range, which covers most industrial sensors. Additionally, the module offers 12-bit resolution, ensuring excellent data precision. Thanks to a conversion time of just 10 µs per input, it responds quickly to rapid changes in sensor data, making it ideal for real-time control systems.

The TSXDSZ32T5 also excels in extreme conditions. It works within an operating temperature range of -10°C to +55°C, while maintaining full functionality in storage temperatures from -40°C to +85°C. This makes it suitable for both indoor and outdoor industrial applications. Furthermore, its DIN rail mounting makes installation simple and convenient in control panels.

Applications

The TSXDSZ32T5 is perfect for a variety of applications where high-precision data conversion is essential. These include:

• Industrial Automation: It collects and processes analog signals from sensors such as temperature, pressure, and flow meters.
• Building Automation: The module monitors environmental parameters like temperature, humidity, and CO2 levels.
• Data Acquisition: It efficiently gathers analog data from different sources for monitoring, control, and analysis.

By converting analog signals into digital data, the TSXDSZ32T5 enhances the performance of PLC systems, allowing for more efficient control and monitoring.
