Schneider DTA 150 Analog Output Module

The Schneider DTA 150 is a high-performance analog output module designed to integrate seamlessly within industrial automation systems. Part of Schneider Electric’s extensive lineup, this module delivers reliable and precise output control in various applications.

Key Features and Specifications

Model: Schneider DTA 150
Product Type: Analog Output Module
Part Number: DTA 150
Weight: 2.45 lbs (1.11 kg)
Input Type: Differential/Self-calibrating
Output Channels: 4 Analog Output Channels
Output Voltage Range: 0–10V DC
Resolution: 16 bits
Output Accuracy: ±0.1% of full scale
Conversion Time: 1 ms per channel
Power Supply: 24V DC
Operating Temperature Range: -20°C to 70°C
Storage Temperature Range: -40°C to 85°C
Mounting Type: Rack Mountable
Communication Protocols: Modbus RTU, Profibus DP
IP Rating: IP20
Operating Altitude: Up to 2,000 meters (6,561 feet)
Response Time: 1 ms per channel
System Compatibility: Compatible with Schneider Electric controllers
Protection Features: Overvoltage, overcurrent protection

Product Overview

The Schneider DTA 150 analog output module is engineered for applications requiring high-accuracy and quick response times. Offering 4 analog output channels, this module handles 0–10V DC signals with 16-bit resolution and boasts an impressive ±0.1% accuracy. Whether used in machine control systems, manufacturing automation, or process control, the DTA 150 ensures high precision and reliable performance.

With a conversion time of just 1 ms per channel, the Schneider DTA 150 meets the demands of high-speed industrial environments. It is equipped with both Modbus RTU and Profibus DP communication protocols, ensuring seamless integration into a variety of industrial control systems.

Applications

The Schneider DTA 150 module is perfect for any application requiring precise analog output control, including robotics, HVAC systems, and motion control systems. Its rack-mountable design ensures compatibility with standard industrial enclosures, making it versatile and easy to install.

Product Details

Brand: Schneider Electric
Category: Analog Output Module
Series: Part of Schneider Electric’s automation range

Technical Specifications

Specification	Details
Model	Schneider DTA 150
Product Type	Analog Output Module
Part Number	DTA 150
Weight	2.45 lbs (1.11 kg)
Input Type	Differential/Self-calibrating
Output Channels	4 Analog Output Channels
Output Voltage Range	0–10V DC
Resolution	16 bits
Output Accuracy	±0.1% of full scale
Conversion Time	1 ms per channel
Power Supply	24V DC
Operating Temperature Range	-20°C to 70°C
Storage Temperature Range	-40°C to 85°C
Mounting Type	Rack Mountable
Communication Protocols	Modbus RTU, Profibus DP
IP Rating	IP20
Operating Altitude	Up to 2,000 meters (6,561 feet)
Response Time	1 ms per channel
System Compatibility	Schneider Electric Controllers
Protection Features	Overvoltage, overcurrent protection
