Schneider ASBDEA201 Modnet Interface Module

Technical Specifications

Parameter	Value
Brand	Schneider
Model	ASBDEA201
Category	Modnet Interface Module
Weight	0.42 lbs (0.19 kg)
Dimensions	3.7 x 2.9 x 2.4 inches
Component Count	94 discrete components
Network Protocol	Modnet (proprietary)
Communication Speed	1.5 Mbps
Transmission Distance	500 meters maximum
Node Capacity	32 nodes per network
Connector Type	9-pin D-sub female
Isolation	1000V AC transformer
Status LEDs	3 (Power, Run, Fault)
Operating Voltage	24V DC from backplane
Current Draw	60 mA at 24V DC
Energy Storage	2 x 100µF, 2 x 47µF
Temperature Range	0°C to 55°C
Wiring Type	Shielded twisted pair

Physical Construction and Component Layout

This ASBDEA201 Modnet interface module measures 3.7 inches in height. Its width reaches 2.9 inches with a depth of 2.4 inches. The total weight comes to approximately 0.42 pounds. Manufacturers placed 94 discrete components on this compact PCB. These components include a network controller, isolation transformers, line drivers, and status LEDs. The board uses a four-layer design for signal integrity.

Network Specifications and Communication Performance

ASBDEA201 implements the proprietary Modnet protocol for industrial networking. The module communicates at a fixed speed of 1.5 megabits per second. Transmission distance reaches up to 500 meters using shielded twisted pair cable. Each Modnet network supports up to 32 connected nodes. A 9-pin D-sub female connector provides the physical network interface. Transformer isolation separates the network from internal logic. This isolation withstands 1000V AC for reliable protection. Consequently, the module operates safely in electrically noisy environments.

Status Indication and Power Requirements

The interface module features three LED indicators for quick diagnostics. A green Power LED shows the presence of 24V DC supply. A green Run LED blinks during normal network operation. A red Fault LED illuminates when communication errors occur. The ASBDEA201 draws only 60 milliamps from the 24V DC backplane. For energy storage, the module integrates two 100µF capacitors. Two additional 47µF capacitors filter high-frequency power noise. These capacitors smooth voltage fluctuations from the backplane supply.

Application Use and System Integration

You will use this module to connect TSX Micro PLCs to Modnet networks. It links processors, HMIs, and remote I/O stations together. The ASBDEA201 operates reliably from 0°C to 55°C ambient. Automatic baud rate detection simplifies network configuration. For example, you can build distributed control systems across a factory floor. Therefore, this interface module provides reliable network connectivity for Schneider automation systems.
